Formation and remodeling of the sinus venosus and the dorsal mesenchymal protrusion in human embryo

doi:10.3969/j.issn.2095-4344.0293

Abstract

Abstract:

BACKGROUND: Formation and remodeling of sinus venosus and the function of the dorsal mesenchymal protrusion (DMP) in human embryonic heart remain controversial.
OBJECTIVE: To explore the function of DMP and the sinus venosus development in the process of human embryo atrial separation.
METHODS: The human embryos were fixed for 24 hours immediately after harvesting, followed by staged based on Carnegie stage (CS10-CS17) under stereo microscope. Serial sections of human embryos were stained immunohistochemically.
RESULTS AND CONCLUSION: During CS10-CS12, the isl1 positive cells of the pharyngeal ventral mesenchyme and the dorsal pericardial wall extended to the sinus venosus wall to contribute to myocardium formation. From CS13, isl1 began to express in the coronary sinus and the caval vein wall and these blood vessels began to be myocardialized. Meanwhile, the isl1 positive cells participated in the formation of DMP.At CS15, the DMP contributed to the atrial separation and was myocardialized gradually. These data suggest that in human embryo, the sinus venosus is formed and the myocardium of the venous tributaries is derived from the isl1 positive cells of second heart field. The formation and function of the DMP in human embryo are similar to those of the mouse embryo.

中国组织工程研究杂志出版内容重点：组织构建；骨细胞；软骨细胞；细胞培养；成纤维细胞；血管内皮细胞；骨质疏松；组织工程

Key words: Venae Cavae, Coronary Sinus, Stromal Cells, Immunohistochemistry, Tissue Engineering

CLC Number:

R318

Yang Yan-ping, Li Hai-rong, Cao Xi-mei, Jing Ya, Cui Hui-lin, Zhang Tao. Formation and remodeling of the sinus venosus and the dorsal mesenchymal protrusion in human embryo[J]. Chinese Journal of Tissue Engineering Research, 2018, 22(20): 3130-3135.

Figures/Tables 2

References

[1] Sun C,Yu D,Ye W,et al.The short stature homeobox 2 (Shox2)-bone morphogenetic protein (BMP) pathway regulates dorsal mesenchymal protrusion development and its temporary function as a pacemaker during cardiogenesis.J Biol Chem.2015;290 (4): 2007-2023.

[2] Zhang KK, Xiang M, Zhou L, et al. Gene network and familial analyses uncover a gene network involving Tbx5/Osr1/Pcsk6 interaction in the second heart field for atrial septation.Hum Mol Genet.2016; 25(6):1140-1151.

[3] Kelder TP,Vicente-Steijn R,Harryvan TJ,et al.The sinus venosus myocardium contributes to the atrioventricular canal: potential role during atrioventricular node development? J Cell Mol Med. 2015;19(6):1375-1389.

[4] Ammirabile G,Tessari A,Pignataro V,et al.Pitx2 confers left morphological, molecular, and functional identity to the sinus venosus myocardium.Cardio Res.2012;93(2): 291-301.

[5] Kim JH,Hwang SE,Rodríguez-Vázquez JF,et al.Upper terminal of the inferior vena cava and development of the heart atriums: a study using human embryos.Anat Cell Biol.2014;47(4):236-243.

[6] Anderson RH,Cook AC.The structure and components of the atrial chambers.Europace.2007;9 (suppl 6), vi3-vi9.

[7] Lescroart F,Mohun T,Meilhac SM,et al.Lineage tree for the venous pole of the heart: clonal analysis clarifies controversial genealogy based on genetic tracing.Circ Res.2012;111 (10): 1313-1322.

[8] Christoffels VM,Mommersteeg MT,Trowe MO,et al.Formation of the venous pole of the heart from an Nkx2-5-negative precursor population requires Tbx18.Circ Res.2006;98(12): 1555-1563.

[9] Mommersteeg MT,Dominguez JN,Wiese C,et al.The sinus venosus progenitors separate and diversify from the first and second heart fields early in development.Cardiovasc Res. 2010;87 (1): 92-101.

[10] O’Rahilly R,Müller F.Developmental Stages in Human Embryos[M].Washington,DC: Carnegie Institution of Washington Publication.1987.

[11] Soufan AT,van den Hoff MJB,Ruijter JM,et al.Reconstruction of the patterns of gene expression in the developing mouse heart reveals an architectural arrangement that facilitates the understanding of atrial malformations and arrhythmias.Circ Res.2004;95(12):1207-1215.

[12] Sizarov A,Anderson RH,Christoffels VM,et al. Three-Dimensional and molecular analysis of the venous pole of the developing human heart.Circulation.2010;122(8): 798-807.

[13] Witzel HR,Cheedipudi S,Gao R,et al.Isl2b regulates anterior second heart field development in zebrafish.Sci Rep.2017;7: 41043.

[14] Yuan XJ,Qi H,Li X,et al.Disruption of spatiotemporal hypoxic signaling causes congenital heart disease in mice.J Clin Invest. 2017;127 (6):2235-2248.

[15] van den Berg G,Moorman AFM.Development of the pulmonary vein and the systemic venous sinus: an interactive 3D overview.PLoS One.2011;6(7):e22055.

[16] Jongbloed MR,Mahtab EA,Blom NA,et al.Development of the cardiac conduction system and the possible relation to predilection sites of arrhythmogenesis.Scientific World J. 2008;8:239-269.

[17] Ye W,Wang J,Song Y,et al.A common Shox2-Nkx2-5 antagonistic mechanism primes the pacemaker cell fate in the pulmonary vein myocardium and sinoatrial node. Development. 2015;142(14): 2521-2532.

[18] Gittenberger-de Groot AC, Mahtab EA, Hahurij ND, et al. Nkx2.5-negative myocardium of the posterior heart field and its correlation with podoplanin expression in cells from the developing cardiac pacemaking and conduction system.Anat Rec.2007;290 (1):115-122.

[19] Burns T,Yang Y,Hiriart E,et al.The dorsal mesenchymal protrusion and the pathogenesis of atrioventricular septal defects.J Cardiovasc Dev Dis.2016;3:29.

[20] Kelder TP,Vicente-Steijn R,Harryvan TJ,et al.The sinus venosus myocardium contributes to the atrioventricular canal: potential role during atrioventricular node development? J Cell Mol Med. 2015;19 (6):1375-1389.
