Differential analysis of plantar pressure parameters of lower limbs in stroke patients with different cerebral hemispheric injuries

doi:10.12307/2022.887

Abstract

Abstract: BACKGROUND: Plantar pressure can effectively assess static standing balance function after stroke. Different hemispheric injuries may cause different plantar pressure performance.
OBJECTIVE: To explore the difference in plantar pressure parameters under static standing in stroke patients with different hemispheric injuries and healthy people.
METHODS: A total of 11 stroke patients with right brain injury (RHD group), 15 stroke patients with left brain injury (LHD group), and 12 healthy subjects (healthy group) were selected from the First Affiliated Hospital of Bengbu Medical College. A footwork dynamic foot force platform was used to detect the plantar dynamic (mean and maximum pressure symmetry index and their corresponding asymmetry index values) and kinematic parameters (center of pressure sway trajectories, including ellipse area, anteroposterior and mediolateral displacement, and corresponding symmetry index values) of each subject during static standing. Each measurement lasted for 10 seconds. Three measurements were conducted in total and their mean values were calculated.
RESULTS AND CONCLUSION: (1) Compared with the healthy group, the mean pressure symmetry index of the forefoot in the RHD group, the maximum pressure symmetry index of the forefoot, and the mean and maximum pressure symmetry indexes of the heel in the LHD group were significantly increased under eyes-open conditions (P < 0.05). (2) Compared with the healthy group, there was a significant increase in the mean pressure symmetry index of the forepfoot and the mean and maximum pressure symmetry indexes of the heel in the RHD (P < 0.05) as well as in the maximum pressure symmetry index of the forefoot and the mean and maximum pressure symmetry indexes of the heel in the LHD group (P < 0.05, P < 0.01) under eyes-closed conditions. (3) The ellipse area and mediolateral displacement symmetry index in the eyes-open state and the mediolateral displacement symmetry index in the eyes-closed state were significantly decreased in the LHD group compared with the healthy group (P < 0.05, P < 0.01). (4) The ellipse area and anteroposterior and mediolateral displacement amplitudes were significantly increased in the RHD and LHD groups compared with the healthy group under eyes-closed conditions (P < 0.05, P < 0.01). (5) Compared with the eyes-open conditions, the anteroposterior displacement amplitude was significantly increased in the RHD group under the eyes-closed conditions, and the ellipse area and anteroposterior and mediolateral displacement amplitudes were significantly increased in the LHD group under the eyes-closed conditions (P < 0.01). (6) To conclude, most stroke patients with left or right hemispheric injury shift their body mass to the healthy side to maintain the body balance, and the force magnitudes of the forefoot and heel are lower on the affected side than the healthy side. Irrespective of unilateral spatial neglect factors, patients with left hemispheric injury have worse balance control on the affected side than the healthy side, and visual information has a greater influence on their static standing stability.

Key words: stroke, left and right brain, dynamic parameter, kinematic parameter, symmetry index, plantar pressure, eyes open, eyes closed, static balance

CLC Number:

Wang Yaoting, Lu Yan, Yao Jiaqin, Yang Chunhua, Xu Wenjing, Wang Hongyu. Differential analysis of plantar pressure parameters of lower limbs in stroke patients with different cerebral hemispheric injuries[J]. Chinese Journal of Tissue Engineering Research, 2022, 26(35): 5646-5651.

Figures/Tables 6

References

[1] Campbell BCV, Khatri P. Stroke. Lancet. 2020;396(10244):129-142.
[2] Sharififar S, Shuster JJ, Bishop MD. Adding electrical stimulation during standard rehabilitation after stroke to improve motor function. A systematic review and meta-analysis. Ann Phys Rehabil Med. 2018; 61(5):339-344.
[3] Hendrickson J, Patterson KK, Inness EL, et al. Relationship between asymmetry of quiet standing balance control and walking post-stroke. Gait Posture. 2014;39(1):177-181.
[4] Ehrhardt A, Hostettler P, Widmer L, et al. Fall-related functional impairments in patients with neurological gait disorder. Sci Rep. 2020; 10(1):21120.
[5] Martins EF, de Araujo BP, de Menezes LT, et al. Is it correct to always consider weight-bearing asymmetrically distributed in individuals with hemiparesis? Physiother Theory Pract. 2011;27(8):566-571.
[6] Spinazzola L, Cubelli R, Della SS. Impairments of trunk movements following left or right hemisphere lesions: dissociation between apraxic errors and postural instability. Brain. 2003;126(Pt 12): 2656-2666.
[7] Rusu L, Paun E, Marin MI, et al. Plantar Pressure and Contact Area Measurement of Foot Abnormalities in Stroke Rehabilitation. Brain Sci. 2021;11(9):1213.
[8] Fernandes CA, Coelho DB, Martinelli AR, et al. Right cerebral hemisphere specialization for quiet and perturbed body balance control: Evidence from unilateral stroke. Hum Mov Sci. 2018;57:374-387.
[9] Chen LC, Cheng PT, Hu AL, et al. Balance evaluation in hemiplegic stroke patients.Chang Gung Med J. 2000;23(6):339-347.
[10] Mansfield A, Danells CJ, Zettel JL, et al. Determinants and consequences for standing balance of spontaneous weight-bearing on the paretic side among individuals with chronic stroke. Gait Posture. 2013;38(3):428-432.
[11] Bakalkin G, Nosova O, Sarkisyan D, et al. Unilateral traumatic brain injury of the left and right hemisphere produces the left hindlimb response in rats. Exp Brain Res. 2021;239(7):2221-2232.
[12] Talis VL, Kazennikov OV. Effects of body turn on postural sway during symmetrical and asymmetrical standing. Exp Brain Res. 2019; 237(9):2231-2237.
[13] 中华医学会神经病学分会,中华医学会神经病学分会脑血管病学组.中国各类主要脑血管病诊断要点2019[J].中华神经科杂志, 2019,52(9):710-715.
[14] Tasseel-Ponche S, Yelnik AP, Bonan IV. Motor strategies of postural control after hemispheric stroke. Neurophysiol Clin. 2015;
45(4-5):327-333.
[15] Niam S, Cheung W, Sullivan PE, et al. Balance and physical impairments after stroke. Arch Phys Med Rehabil. 1999;80(10):1227-1233.
[16] Choi H, Kim WS. Anterior-posterior displacement of center of pressure measured by insole foot pressure measurement system in subacute recovery stage of post-stroke hemiplegia. Technol Health Care. 2018;26(4):649-657.
[17] Hillier S, Lai MS. Insole plantar pressure measurement during quiet stance post stroke. Top Stroke Rehabil. 2009;16(3):189-195.
[18] 魏孟田,及化娟,李立.足底压力测试技术在不同人群中的应用[J].中国组织工程研究与临床康复,2010,14(50):9425-9428.
[19] Güntürkün O, Ströckens F, Ocklenburg S. Brain Lateralization: A Comparative Perspective. Physiol Rev. 2020;100(3):1019-1063.
[20] Heilman KM, Bowers D, Valenstein E, et al. The right hemisphere: neuropsychological functions. J Neurosurg. 1986;64(5):693-704.
[21] Frenkel-Toledo S, Fridberg G, Ofir S, et al. Lesion location impact on functional recovery of the hemiparetic upper limb. PLoS One. 2019;14(7):e0219738.
[22] Frenkel-Toledo S, Ofir-Geva S, Mansano L, et al. Stroke Lesion Impact on Lower Limb Function. Front Hum Neurosci. 2021;15:592975.
[23] 林强,陈武德,郑煜欣,等.基于足底压力下睁闭眼对静态平衡功能的影响[J].康复学报,2021,31(1):17-23.
[24] 林强,郑煜欣,廖婉晨,等.脑卒中患者静态平衡的足底压力分析[J].中国康复理论与实践,2021,27(3):290-296.
[25] Pereira LC, Botelho AC, Martins EF. Relationships between body symmetry during weight-bearing and functional reach among chronic hemiparetic patients. Rev Bras Fisioter. 2010;14(3):229-266.
[26] Roerdink M, Geurts AC, de Haart M, et al. On the relative contribution of the paretic leg to the control of posture after stroke. Neurorehabil Neural Repair. 2009;23(3):267-274.
[27] Vieira TM, Lemos T, Oliveira LAS, et al. Postural Muscle Unit Plasticity in Stroke Survivors: Altered Distribution of Gastrocnemius’ Action Potentials. Front Neurol. 2019;10:686.
[28] Ishii F, Matsukawa N, Horiba M, et al. Impaired ability to shift weight onto the non-paretic leg in right-cortical brain-damaged patients. Clin Neurol Neurosurg. 2010;112(5):406-412.
[29] Mani S, Mutha PK, Przybyla A, et al. Contralesional motor deficits after unilateral stroke reflect hemisphere-specific control mechanisms. Brain. 2013;136(Pt 4):1288-1303.
[39] Vidal AC, Banca P, Pascoal AG, et al. Bilateral versus ipsilesional cortico-subcortical activity patterns in stroke show hemispheric dependence. Int J Stroke. 2018;1747493018767164.
[31] Dieterich M, Brandt T. Global orientation in space and the lateralization of brain functions. Curr Opin Neurol. 2018;31(1):96-104.
[32] Chen IH, Novak V, Manor B. Infarct hemisphere and noninfarcted brain volumes affect locomotor performance following stroke. Neurology. 2014;82(10):828-834.
[33] Hedna VS, Bodhit AN, Ansari S, et al. Hemispheric differences in ischemic stroke: is left-hemisphere stroke more common? J Clin Neurol. 2013;9(2):97-102.
[34] Hugues A, Di Marco J, Ribault S, et al. Limited evidence of physical therapy on balance after stroke: A systematic review and meta-analysis. PLoS One. 2019;14(8):e0221700.
