Three-dimensional culture and differentiation of biological bone tissue and its in vivo repair effect in an animal model

doi:10.3969/j.issn.2095-4344.2017.06.003

Abstract

Abstract:

BACKGROUND: In vitro culture of tissue-engineered bone is an important method for bone repair. Three-dimensional (3D) printed bone stents combined with bioreactor culture are of significance in bone tissue engineering.
OBJECTIVE: To study the in vivo repair effect of the 3D printed biomaterial scaffold with human mesenchymal stem cells (hMSCs) cultured in bioreactor.
METHODS: The scaffold was constructed by poly(lactic-co-glycollic acid)/hydroxyapatite (PLGA/HA) via 3D printing and freeze-dying techniques, and then hMSCs were seeded onto the scaffold and cultured in bioreactors. All rabbits were numbered and divided into control (No.1 and 2), experimental 1 (No. 3 and 4) and experimental 2 (No. 5 and 6) groups, and each group had two subgroups positive and negative. The rabbit left distal femur in each group was modeled into bone defect and the single PLGA/HA scaffold, PLGA/HA scaffold carrying non-induced hMSCs were implanted in the positive and negative groups of the control group, respectively; the PLGA/HA-201 405-1 and PLGA/HA-201 405-2 carrying induced hMSCs were implanted into the positive and negative subgroups of the experimental 1 and 2 groups, respectively. Additionally, the right femur in the experimental 2 group was drilled only. The osteogenesis ability and biodegradability were determined using electron microscope, the in vivo repair was observed through CT examination, and the histopathological examination was performed after bone healing.
RESULTS AND CONCLUSION: The scaffold with topological structure suitable for cell seeding was prepared. A large number of new calcium nodules were observed under electron microscope in the experimental groups indicating overt achievement in bone healing. These results suggest that the prepared scaffold achieves a good repair effect preliminarily.

中国组织工程研究杂志出版内容重点：生物材料；骨生物材料; 口腔生物材料; 纳米材料; 缓释材料; 材料相容性；组织工程

Key words: Biocompatible Materials, Cell Differentiation, Bioreactors, Bone and Bones, Tissue Engineering

CLC Number:

R318

Wang Yan1, Wang Han-zhong2, Zhang Ying1, Zhang Li-jun1, Tian Jian-ming2, Chen Xian-xiong3 . Three-dimensional culture and differentiation of biological bone tissue and its in vivo repair effect in an animal model [J]. Chinese Journal of Tissue Engineering Research, 2017, 21(6): 836-842.

Figures/Tables 5

References

[1]费小琛,颜永年,熊卓,等.骨组织工程PLGA/TCP复合材料的性能研究[J].材料导报,2003,17(12): 76-79.

[2]贾帅军,孟国林,刘建,等.胶原修饰快速成形PLGA/TCP人工骨支架体外生物相容性研究[J].科学技术与工程, 2009,9(12):3207-3211.

[3]Tali R, Yael KI, Emil R, et al. Chondrogenesis of hMSC in affinity-bound TGF-beta scaffolds. Biomaterials.2012;33(3): 751-761.

[4]黄永辉,夏青,沈铁城,等. 人骨髓间充质干细胞接种纳米晶胶原骨构建组织工程骨[J].生物骨科材料与临床研究,2008,5(1): 1-3.

[5]Kim HJ, Kim UJ, Kim HS, et al. Bone tissue engineering with premineralized silk scaffolds. Bone.2008;42(6): 1226-1234.

[6]Robert F.Service.Tissue engineers build new bone. Science. 2000;289 (5984) :1498-1500.

[7]Langer R, Vacanti JP.Tissue engineering. Science. 1993;260: 920-926.

[8]Martin I, Wendt D, Heberer M.The role of bioreactors in tissue engineering. Trends Biotechnol.2004;22(2) :80-86.

[9]Chen HC, Hu YC.Bioreactors for tissue engineering. Biotechnol Lett.2006;28 (18) :1415-1423.

[10]Bilodeau K, Mantovan D.Bioreactors for tissue engineering: focus on mechanical constraints. A comparative review. Tissue Eng.2006;12(8):2367-2383.

[11]王妍,伍活廉,张丽君,等. 一种生物反应罐;中国, 201420151906. 9[P].2014-11-12.

[12]刘晓晨,贾文霄,金格勒,等.MRI、CT、X线对兔腰椎融合术后的比较性实验研究[J].中国医学计算机像,2011,17(1):75-79.

[13]韩耀坤,贾秀月,娄大力,等.同种异体骨髓基质干细胞治疗骨缺损的实验研究[J].中国病案，2012,13(8):61-63.

[14]车向新,曹俊,黄小林,等.自制诱导型人工骨材料修复兔颅骨缺损实验研究[J].中国现代医学杂志，2013,23(14):11-17.

[15]王飞,王妍,程律莎,等. hMSCs的成骨定向分化及与PLGA/TCP的相容性[J]. 华南理工大学学报:自然科学版,2014, 42(11): 143-148.

[16]Wang F,Zhang LJ, Wang Y,et al. Feeder-Culture Bioreactors Inducing Osteogenic and Chondrogenic Differentiation of Human Mesenchymal Stem Cells on Polylactic Glycolic Acid/Tricalcium Phosphate (PLGA/TCP) Scaffolds. Journal of biomaterials and tissue engineering. 2015;5(7): 557-564.

[17]Das S,Hollister S,Flangan C.Freeform fabrication of Nylon-6 tissue engineering scaffolds.Rapid Prototyping J.2003;9(1): 43-49.

[18]Nam YS,Park TG.Biodegradable poiymeric microcellular foams by modified thermally induced phase separation method.Biomaterials.1999;20(19):1783-1790.

[19]Mikos AG, Thorsen AJ, Czerwonka LA, et al. Preparation and Characterization of Poly (L -Lactic Acid) Foams. Polymer. 1994;35(5):1068-1077.

[20]Doshi J, Reneker DH. Electrospinning Process and Applications of Electrospun Fibers. Electrostatics. 1995; 35(2-3):151-160.

[21]Hutmacher DW, Schantz T, Zein I, et al. Mechanical properties and cell cultural response of polycaprolactone scaffolds designed and fabricated via fused deposition modeling. J Biomed Mater Res.2001;55(2):203-216.

[22]Li S. Hydrolytic degradation characteristics of aliphatic polyesters derived from lactic and glycolic acids. J Biomed Mater Res.1999;48(3):342-353.

[23]Attawia MA, Herbert KM, Laurencin CT. Osteoblast-like cell adherance and migration through 3-dimensional porous polymer matrices. BiochemBiophys Res Commun. 1996;8(1):63-75.

[24]陈思诗,杨庆,沈新元,等.溶剂浇铸-粒子沥滤法制备PBS/PCL组织工程支架[J]. 东华大学学报,2009,35(4):391-395.

[25]Huang YC,Mooney DJ.Gas foaming to fabricate polymer scaffolds in tissue engineering. Scaffoldings in tissue engineering.2005:159.

[26]Bose S, Vahabzadeh S, Bandyopadhyay A.Bone tissue engineering using 3D Printing. Materials Today.2013;16 (12) :496-504.

[27]Tarafder S,Balla VK,Davies NM.Microwave Sintered 3D Printed Tricalcium Phosphate Scaffolds for Bone Tissue Engineering.J Tissue Eng Regen Med.2013；7(8): 631–641.

[28]Cox SC, Thornby JA, Gibbons GJ, et al.3D printing of porous hydroxyapatite scaffolds intended for use in bone tissue engineering applications.Mater Sci Eng C Mater Biol Appl. 2015;47:237-247.

[29]Inzana A, Olvera D, Fuller M.3D printing of composite calcium phosphate and collagen scaffolds for bone regeneration. Biomaterials.2014;35(13):4026-4034.

[30]宋克东,刘庆天,李香琴,等.新型旋转式生物反应器内三维组织工程骨的构建[J].生物化学与生物物理进展, 2004,31(11): 996-1005.

[31]Rauh J,Milan F,Günther KP.Bioreactor systems for bone tissue engineering.Tissue Engineering Part B: Reviews.2011; 17(4):263-280.

[32]Zhang ZY, Teoh SH, Teo EY, et al.A comparison of bioreactors for culture of fetal mesenchymal stem cells for bone tissue engineering .Biomaterials.2010;31(33) :8684-8695.

[33]Nishi M,Matsumoto R,Dong J,et al.Engineered bone tissue associated with vascularization utilizing a rotating wall vessel bioreactor.J Biomed Mater Res A.2013;101(2):421-427.

[34]陈孝平,汪建平.外科学[M].北京:人民卫生出版社,2013: 634-635.
