Materials biocompatibility in the internal fixation of pelvic fracture combined with acetabular fracture

doi:10.3969/j.issn.2095-4344.2015.25.031

Abstract

Abstract:

BACKGROUND: Pelvic fractures combined with acetabular fractures are mostly caused by high-energy violence, often accompanied by severe complications and high mortality, and surgical fixation is preferred in most cases.
OBJECTIVE: To investigate the internal fixation of pelvic fracture combined with acetabular fracture and to analyze the material biocompatibility.
METHODS: A computer-based search of Wanfang, CNKI and PubMed databases was performed for articles related to the internal fixation of pelvic fracture combined with acetabular fracture and material biocompatibility published from 2005 to 2014. The keywords were “pelvis fractures, acetabulum fractures, internal fixators, materials” in Chinese and English, respectively. Articles published in authoritative journals or recently were preferred, and finally 29 articles were enrolled in result analysis.
RESULTS AND CONCLUSION: Steel plate reconstruction or screw internal fixation is often used for clinical treatment of pelvic fracture combined with acetabular fracture. Titanium plate is often chosen with similar elastic modulus to the bone and good biocompatibility. The titanium plate is pre-bended before implantation to match the bone surface of the fracture site. Absorbable screws have good histocompatibility and non-toxic side effects, which can avoid the electrolysis and corrosion of metal screws and maintain certain strength in early period of internal fixation; over time, the fracture is gradually healed, the material strength gradually decreases, and the material is finally degraded into water and carbon dioxide to achieve good clinical outcomes. It is difficult and high-risk for treatment of pelvic fracture combined with acetabular fractures, and active treatment and damage control are recommended as soon as possible. A reasonable treatment plan can be developed based on the type of fracture. Plate internal fixation and minimally invasive fixation developed by the three-dimensional reconstruction techniques show a great progress in fracture treatment, which have broad clinical application prospects.

中国组织工程研究杂志出版内容重点：生物材料；骨生物材料; 口腔生物材料; 纳米材料; 缓释材料; 材料相容性；组织工程

Key words: Biocompatible Materials, Bone Remodeling, Bone Nails, Pelvis, Acetabulum

CLC Number:

R318

Gao Ming-jie, Tao Jie, Zhou Zi-hui, Du Lin. Materials biocompatibility in the internal fixation of pelvic fracture combined with acetabular fracture[J]. Chinese Journal of Tissue Engineering Research, 2015, 19(25): 4096-4100.

Figures/Tables 2

References

[1] Davarinos N, Ellanti P, Morris S, et al.Epidemiology of pelvic and acetabular trauma in a Dublin tertiary hospital: a 10-year experience.Ir J Med Sci.2012;181(2):243-246.

[2] Harvie P, Chesser TJ, Ward AJ.The Bristol regional pelvic and acetabular fracture service: workload implications of managing the polytraumatised patient.Injury.2008;39(8): 839-843.

[3] Lefaivre KA, Slobogean GP, Valeriote J, et al.Reporting and interpretation of the functional outcomes after the surgical treatment of disruptions of the pelvic ring: a systematic review. J Bone Joint Surg Br.2012;94(4):549-555.

[4] 张立群,林建华.多发性损伤合并骨盆骨折的处理[J].国际骨科学杂志,2012,33(1):39-40.

[5] 周强,张义万,赵建军.重建钛钢板治疗不稳定骨盆骨折并髋臼骨折70例临床分析[J].临床合理用药,2012,6(1A):98-99.

[6] 肖增明,詹新立,李世德,等.采用联合入路治疗复杂型陈旧性髋臼骨折[J].中华创伤骨科杂志,2005,7(12):1121-1123.

[7] 纪少军,康锦,高杰.手术治疗C型髋臼骨折的研究分析[J].河北医学,2014,20(9):1438-1440.

[8] 朱仕文,王满宜,吴新宝,等.经单一髂腹股沟入路治疗复合髋臼骨折[J].中华创伤骨科杂志,2005,7(11):1025-1027.

[9] Xu M, Zhang LH, Zhang YZ, et al.Custom-made locked plating for acetabular fracture: a pilot study in 24 consecutive cases.Orthopedics.2014;37(7):e660-670.

[10] Scheyerer MJ, Zimmermann SM, Osterhoff G, et al.Anterior subcutaneous internal fixation for treatment of unstable pelvic fractures.BMC Res Notes.2014;7:133.

[11] Chen PH, Hsu WH, Li YY, et al.Outcome analysis of unstable posterior ring injury of the pelvis: comparison between percutaneous iliosacral screw fixation and conservative treatment.Biomed J.2013;36(6):289-294.

[12] Koo H, Leveridge M, Thompson C, et al.Interobserver reliability of the young-burgess and tile classification systems for fractures of the pelvic ring.J Orthop Trauma.2008; 22(6): 379-384.

[13] OTA.Fracture and dislocation compendium. Orthopaedic Trauma Association Committee for Coding and Classification. J Orthop Trauma;2007;10(Suppl):S1-S163.

[14] Qin X, Li X, Lü T, et al.An anatomical study and clinical evaluation of modified subinguinal approach for treatment of acetabular fractures.Zhongguo Xiu Fu Chong Jian Wai Ke Za Zhi.2014;28(1):47-52.

[15] Garrett J, Halvorson J, Carroll E, et al.Value of 3-D CT in classifying acetabular fractures during orthopedic residency training.Orthopedics.2012;35(5):e615-620.

[16] 黄婉静,田京.三维重建在骨盆和髋臼骨折中的运用[J].中国组织工程研究,2014,18(9):1416-1421.

[17] Grossterlinden L, Nuechtern J, Begemann PG, et al. Computer-assisted surgery and intraoperative three-dimensional imaging for screw placement in different pelvic regions.J Trauma.2011;71(4):926-932.

[18] Duchesne JC, Barbeau JM, Islam TM, et al.Damage control resuscitation: from emergency department to the operating room.Am Surg.2011;77(2):201-206.

[19] Halvorson JJ, Lamothe J, Martin CR, et al.Combined acetabulum and pelvic ring injuries.J Am Acad Orthop Surg. 2014;22(5):304-314.

[20] Gänsslen A, Krettek C.Retrograde transpubic screw fixation of transpubic instabilities.Oper Orthop Traumatol.2006;18(4): 330-340.

[21] Papakostidis C, Kanakaris N, Dimitriou R, et al.The role of arterial embolization in controlling pelvic fracture haemorrhage: a systematic review of the literature.Eur J Radiol.2012;81(5):897-904.

[22] Alexa O, Malancea RI, Puha B, et al.Results of surgical treatment of acetabular fractures using Kocher-Langenbeck approach.Chirurgia (Bucur).2013;108(6):879-885.

[23] Seyyed Hosseinzadeh HR, Eajazi A, Hassas Yeganeh M, et al.Modified ilioinguinal approach to the acetabulum and pelvis from beneath the inguinal ligament: a subinguinal approach. Hip Int.2010;20(2):150-155.

[24] Griffin DB, Beaulé PE, Matta JM.Safety and efficacy of the extended iliofemoral approach in the treatment of complex fractures of the acetabulum.J Bone Joint Surg Br.2005; 87(10):1391-1396.

[25] Lao A, Soenen M, Girard J, et al.Anterior hip subluxation following fixation of a T-shaped acetabular fracture through an extended iliofemoral approach.Orthop Traumatol Surg Res. 2011; 97(1):89-93.

[26] Hirvensalo E, Lindahl J, Kiljunen V.Modified and new approaches for pelvic and acetabular surgery.Injury.2007; 38(4):431-441.

[27] Taller S, Srám J, Lukás R, et al.Surgical treatment of pelvic ring and acetabular fractures using the Stoppa approach.Acta Chir Orthop Traumatol Cech.2010;77(2):93-98.

[28] Kacra BK, Arazi M, Cicekcibasi AE, et al.Modified medial Stoppa approach for acetabular fractures: an anatomic study.J Trauma.2011;71(5):1340-1344.

[29] Vikmanis A, Vikmanis A, Jakusonoka R, et al.Mid-term outcome of patients with pelvic and acetabular fractures following internal fixation through a modified Stoppa approach. Acta Orthop Belg.2013;79(6):660-666..

[30] 王瑞雄,陈夏平,刘志强,等.改良Stoppa入路在髋臼及骨盆骨折的手术治疗中的应用[J].中国骨与关节损伤杂志,2014,29(2): 108-110.

[31] Rocca G, Spina M, Mazzi M.Anterior Combined Endopelvic (ACE) approach for the treatment of acetabular and pelvic ring fractures: A new proposal.Injury.2014;45 Suppl 6:S9-S15.
