Bone marrow mesenchymal stem cells combined with acellular
dermal matrix repair beagle dog articular cartilage defects

doi:10.3969/j.issn.2095-4344.1405

Abstract

Abstract:

BACKGROUND: Dermis-derived extracellular matrix, as a cartilage repair scaffold, provides a space for the growth of cartilage tissue, and promotes cell adhesion and proliferation. Bone marrow mesenchymal stem cells have the potential to differentiate into chondrocytes. Both of them used alone have disadvantages.

OBJECTIVE: To evaluate the feasibility of bone marrow mesenchymal stem cells combined with calf acellular dermal matrix to repair beagle dog articular cartilage defects.

METHODS: Beagle dog bone marrow blood was extracted from Beagle dogs. Bone marrow mesenchymal stem cells were obtained by density gradient centrifugation and passaged. Acellular dermal matrix was prepared from the dorsal dermis of neonatal calves by ultrasonic oscillation, freeze-drying and pepsin. 0.2 mL of cell suspension was added to the surface of acellular dermal matrix until covered, then which was placed in a 5% CO₂ incubator at 37 °C for 48 hours. Twelve adult beagle dogs were used to establish knee joint cartilage defect models, and then randomized into three groups: In the acellular dermal matrix combined with bone marrow mesenchymal stem cells group (combination group), cartilage defects were repaired with acellular dermal matrix combined with bone marrow mesenchymal stem cells. In the single acellular dermal matrix group, cartilage defects were repaired with acellular dermal matrix. The model control group received no treatment. At 12 weeks after surgery, the right knee joints were observed by stereomicroscope, hematoxylin-eosin staining and type II collagen immunohistochemical staining.

RESULTS AND CONCLUSION: (1) Scanning electron microscopy showed that bone marrow mesenchymal stem cells adhered to and grew well in the acellular dermal matrix. (2) Hematoxylin-eosin staining revealed that the repaired surface in the combination group was slightly lower than that of the surrounding normal tissues, and the repaired tissues integrated well with the surrounding cartilages. The defects in the single acellular dermal matrix group were filled with fibrous tissues. Few surrounding tissues of defect were repaired in the model control group. (3) Type II collagen immunohistochemical staining showed that in the combination group, articular cartilage defects were filled with chondrocyte-like tissues. In the single acellular dermal matrix group, the defect was filled with fibrous tissues. No tissue was found in the model control group. (4) These results indicate that the new calf acellular dermal matrix has good biocompatibility and can promote the proliferation of bone marrow mesenchymal stem cells. Autologous bone marrow mesenchymal stem cells combined with acellular dermal matrix can effectively repair beagle dog knee joint cartilage defects.

Key words: bone marrow mesenchymal stem cells, acellular dermal matrix, knee joint cartilage defects, chondrocyte-like tissues, cell adhesion, cell proliferation

CLC Number:

Jin Shaofeng, Zheng Rui, Jie Yongsheng, Chen Lei, Qi Hui, Sun Lei, Shu Xiong. Bone marrow mesenchymal stem cells combined with acellular dermal matrix repair beagle dog articular cartilage defects [J]. Chinese Journal of Tissue Engineering Research, 2020, 24(4): 532-537.

Figures/Tables 6

References

[1] NEGORO T, TAKAGAKI Y, OKURA H, et al. Trends in clinical trials for articular cartilage repair by cell therapy. NPJ Regen Med. 2018;3:17.
[2] O'CONOR CJ, CASE N, GUILAK F. Mechanical regulation of chondrogenesis. Stem Cell Res Ther. 2013;4(4):61.
[3] MATSIKO A, LEVINGSTONE TJ, O'BRIEN FJ. Advanced Strategies for Articular Cartilage Defect Repair. Materials (Basel). 2013; 6(2):637-668.
[4] MEDVEDEVA EV, GREBENIK EA, GORNOSTAEVA SN, et al. Repair of Damaged Articular Cartilage: Current Approaches and Future Directions. Int J Mol Sci. 2018;19(8): E2366.
[5] FOSS C, MIGLIARESI C, MOTTA A. The optimization of a scaffold for cartilage regeneration. Organogenesis. 2013;9(1): 19-21.
[6] VEGA SL, KWON MY, BURDICK JA. Recent advances in hydrogels for cartilage tissue engineering. Eur Cell Mater. 2017;33:59-75.
[7] LI F, TRUONG VX, FISCH P, et al. Cartilage tissue formation through assembly of microgels containing mesenchymal stem cells. Acta Biomater. 2018;77:48-62.
[8] LI X, WANG M, JING X, et al. Bone Marrow- and Adipose Tissue-Derived Mesenchymal Stem Cells: Characterization, Differentiation, and Applications in Cartilage Tissue Engineering. Crit Rev Eukaryot Gene Expr. 2018;28(4): 285-310.
[9] GUGJOO MB, AMARPAL, SHARMA GT, et al. Cartilage tissue engineering: Role of mesenchymal stem cells along with growth factors & scaffolds. Indian J Med Res. 2016; 144(3): 339-347.
[10] SQUILLARO T, PELUSO G, GALDERISI U. Clinical Trials With Mesenchymal Stem Cells: An Update. Cell Transplant. 2016;25(5):829-848.
[11] KRISTJÁNSSON B, HONSAWEK S. Mesenchymal stem cells for cartilage regeneration in osteoarthritis. World J Orthop. 2017;8(9):674-680.
[12] ARMIENTO AR, STODDART MJ, ALINI M, et al. Biomaterials for articular cartilage tissue engineering: Learning from biology. Acta Biomater. 2018;65:1-20.
[13] CUNNIFFE GM, DÍAZ-PAYNO PJ, SHEEHY EJ, et al. Tissue-specific extracellular matrix scaffolds for the regeneration of spatially complex musculoskeletal tissues. Biomaterials. 2019;188:63-73.
[14] 綦惠,杰永生,陈磊,等.脱细胞真皮基质制备及其生物相容性研究[J].中国修复重建外科杂志,2014,28(6):768-772.
[15] LEE WY, WANG B. Cartilage repair by mesenchymal stem cells: Clinical trial update and perspectives. J Orthop Translat. 2017; 9:76-88.
[16] KWON H, PASCHOS NK, HU JC, et al. Articular cartilage tissue engineering: the role of signaling molecules. Cell Mol Life Sci. 2016;73(6):1173-1194.
[17] JIANG Y, CAI Y, ZHANG W, et al. Human Cartilage-Derived Progenitor Cells From Committed Chondrocytes for Efficient Cartilage Repair and Regeneration. Stem Cells Transl Med. 2016;5(6):733-744.
[18] CHEN YC, CHEN RN, JHAN HJ, et al. Development and Characterization of Acellular Extracellular Matrix Scaffolds from Porcine Menisci for Use in Cartilage Tissue Engineering. Tissue Eng Part C Methods. 2015;21(9):971-986.
[19] SUTHERLAND AJ, CONVERSE GL, HOPKINS RA, et al. The bioactivity of cartilage extracellular matrix in articular cartilage regeneration. Adv Healthc Mater. 2015;4(1):29-39.
[20] WANG Y, MENG H, YUAN X, et al. Fabrication and in vitro evaluation of an articular cartilage extracellular matrix-hydroxyapatite bilayered scaffold with low permeability for interface tissue engineering. Biomed Eng Online. 2014;13: 80.
[21] YANG Q, TENG BH, WANG LN, et al. Silk fibroin/cartilage extracellular matrix scaffolds with sequential delivery of TGF-β3 for chondrogenic differentiation of adipose-derived stem cells. Int J Nanomedicine. 2017;12:6721-6733.
[22] 舒雄,郑蕊,杰永生,等.脂肪干细胞复合真皮脱细胞基质修复兔关节软骨缺损的实验研究[J].中国医药生物技术, 2017,12(2): 143-148.
[23] SHI Y, ZHOU K, ZHANG W, et al. Microgrooved topographical surface directs tenogenic lineage specific differentiation of mouse tendon derived stem cells. Biomed Mater. 2017;12(1): 015013
[24] YUN S, KU SK, KWON YS. Adipose-derived mesenchymal stem cells and platelet-rich plasma synergistically ameliorate the surgical-induced osteoarthritis in Beagle dogs. J Orthop Surg Res. 2016;11:9.
[25] KO JY, IM GI. Chondrogenic and Osteogenic Induction from iPS Cells. Methods Mol Biol. 2016;1357:441-450.
[26] MCKEE C, HONG Y, YAO D, et al. Compression Induced Chondrogenic Differentiation of Embryonic Stem Cells in Three-Dimensional Polydimethylsiloxane Scaffolds. Tissue Eng Part A. 2017;23(9-10):426-435.
[27] LEE PT, LI WJ. Chondrogenesis of Embryonic Stem Cell-Derived Mesenchymal Stem Cells Induced by TGFβ1 and BMP7 Through Increased TGFβ Receptor Expression and Endogenous TGFβ1 Production. J Cell Biochem. 2017; 118(1):172-181.
[28] 綦惠,杰永生,陈磊,等. 无细胞支架修复家兔关节软骨缺损的实验研究[J]. 中国矫形外科杂志,2015,23(14):1303-1309.
[29] 綦惠,孙磊,陈磊,等.应用小牛皮制备软骨修复载体的脱毛-脱细胞-结构改建工艺探讨[J]. 中国矫形外科杂志, 2014,22(2): 151-157.
[30] WANG C, ZANG H, ZHOU D. Bone morphogenetic protein-2 exhibits therapeutic benefits for osteonecrosis of the femoral head through induction of cartilage and bone cells. Exp Ther Med. 2018;15(5):4298-4308.
[31] DENG ZH, LI YS, GAO X, et al. Bone morphogenetic proteins for articular cartilage regeneration. Osteoarthritis Cartilage. 2018;26(9):1153-1161.
[32] AMANN E, WOLFF P, BREEL E, et al. Hyaluronic acid facilitates chondrogenesis and matrix deposition of human adipose derived mesenchymal stem cells and human chondrocytes co-cultures. Acta Biomater. 2017;52:130-144.
[33] HEILIG J, PAULSSON M, ZAUCKE F. Insulin-like growth factor 1 receptor (IGF1R) signaling regulates osterix expression and cartilage matrix mineralization during endochondral ossification. Bone. 2016;83:48-57.
[34] SIVANDZADE F, MASHAYEKHAN S. Design and fabrication of injectable microcarriers composed of acellular cartilage matrix and chitosan. J Biomater Sci Polym Ed. 2018;29(6): 683-700.
[35] LI YY, CHOY TH, HO FC, et al. Scaffold composition affects cytoskeleton organization, cell-matrix interaction and the cellular fate of human mesenchymal stem cells upon chondrogenic differentiation. Biomaterials. 2015;52:208-220.
[36] YANG W, CAO Y, ZHANG Z, et al. Targeted delivery of FGF2 to subchondral bone enhanced the repair of articular cartilage defect. Acta Biomater. 2018;69:170-182.
[37] GONZALEZ-FERNANDEZ T, TIERNEY EG, CUNNIFFE GM, et al. Gene Delivery of TGF-β3 and BMP2 in an MSC-Laden Alginate Hydrogel for Articular Cartilage and Endochondral Bone Tissue Engineering. Tissue Eng Part A. 2016;22(9-10): 776-787.
