Hip-spine syndrome: pathological base and biomechanics mechanism

doi:10.3969/j.issn.2095-4344.2015.33.023

Abstract

Abstract:

BACKGROUND: Low back pain in patients with hip osteoarthritis can be relieved to some extent after total hip arthroplasty, indicating the changes in limb line of force have obvious effects on low back pain.

OBJECTIVE: To review and analysis the pathological base and biomechanics mechanism of hip-spine syndrome.

METHODS: We retrieved PubMed database and China National Knowledge Infrastructure for related articles published from January 1976 to March 2015. The key words were “low back pain, hip-spine syndrome, hip osteoarthritis, total hip replacement, biomechanics, balance parameters” in English and Chinese, respectively. Repeated studies and unrelated articles were excluded.

RESULTS AND CONCLUSION: A total of 145 articles were retrieved, and finally 62 articles were enrolled in result analysis. In the pathophysiology, tumor necrosis factor-α, interleukin-1β and matrix metalloproteinases play a significant role in the occurrence and development of hip-spine syndrome. As for the biological biomechanics, the spine-pelvic-lower limb balance compensatory process can be the main mechanical mechanism of hip-spine syndrome, and the balance parameters can provide a basis for the diagnosis, treatment and postoperative evaluation of hip-spine syndrome.

中国组织工程研究杂志出版内容重点：组织构建；骨细胞；软骨细胞；细胞培养；成纤维细胞；血管内皮细胞；骨质疏松；组织工程

Key words: Low Back Pain, Hip Joint, Osteoarthritis, Biomechanics

CLC Number:

R318

Wang Qiang, Zhao Wen-jie, Zhang Bin, Dai Min. Hip-spine syndrome: pathological base and biomechanics mechanism[J]. Chinese Journal of Tissue Engineering Research, 2015, 19(33): 5371-5377.

Figures/Tables 3

References

[1] Boswell MV,Shah RV,Everett CR，et al.Interventional techniques in the management of chronic spinal pain:Evidencebased practice guidelines.Pain Physician.2005;8:1-47.
[2] Offierski CM, MacNab I.Hip-spine syndrome.Spine. 1983; 8(3):316-321.
[3] Katz JN, Lipson SJ, Larson MG, et al. The outcome of decompressive laminectomy for degenerative lumbar stenosis. J Bone Joint Surg Am.1991;73:809-816.
[4] Dreyer SJ，Dreyfuss PH.Low back pain and the zygapophysial(facet) joints. Arch Phys Med Rehabil. 1996;77:290-300.
[5] 李旭,尚希褔,张文志,等.全髋置换术对髋-脊综合征患者下腰痛症状影响的相关研究[J].安徽医学,2012,33(4):419-420.
[6] Polkowski GG, Clohisy JC. Hip Biomechanics.Sports M＆Arthroscopy R.2010;6(18):56-62．
[7] 方舒锴,史晨辉.骨性关节炎发病机制研究进展[J].农垦医学, 2010,32(1):68-71.
[8] Femaodes JC, Martel-Pelletier J, Pelletier JP.The role of eytokines in osteoarthritis pathophysiology. Biorheology. 2002;39(1-2):237-246．
[9] Ouchi N, Kihara S, Funahashi T, et al. Reciprocal association of Creactive protein with adiponectin in blood stream and adipose tissue.Circulation.2003; 107:671-674.
[10] Chen TH, Chen L, Hsieh MS, et al. Evidence for a protective role for adiponectin in osteoarthritis. Biochim Biophys Acta. 2006;1762(8):711-718.
[11] Honsawek S, Chayanupatkul M..Correlation of Plasma and Synovial Fluid Adiponectin with Knee Osteoarthritis Severity. Archives of Medical Research.2010;42:593-598.
[12] Perruccio AV,Mahomed NN,Chandran V,et al.Plasma adipokine levels and their association with overall burden of painful jionts among individuals eith hip and knee osteoarthritis. J Rheumatol.2014;41(2):334-337.
[13] de Boer TN,van Spil WE,Huisman AM,et al.Serum adipokines in osteoarthritis;comparison with controls and relationship with local parameters of synovial inflammation and cartilage damage.Osteoarthritis Cartilage.2012;20(8):846-853.
[14] 简晓蕾,张柳. 骨关节炎中的基质金属蛋白酶及其抑制剂[J]. 中国保健营养:中旬刊,2014,24(1): 29-30.
[15] Sally RF.Piece BS,Babak JM. et al. Transforming growth factor beta superfamily members:Role in cartilage modeling. Plastn Reconstr Surg.2000;5:980.
[16] 林文生,张农,张颂文,等.大鼠肾脏系膜细胞转染人TGF-1可增强MMP-2表达[J].上海医科大学学报,2000,27(1):13.
[17] Lotz M. The role of nitric oxide in articular cartilage damage.Rheum Dis Clin North Am.1999;25:269-282.
[18] 韩冬梅,高春阳,张延辉,等.患者退变软骨及滑膜组织中一氧化氮的表达及意义[J].中国生化药物杂志, 2011,32(3): 245-248.
[19] 宋维亚,厉小梅,李向培,等. T细胞在骨关节炎发病机制中的作用[J].安徽医药, 2010,14(4):476-478.
[20] Sakkas LI, Scanzello C,Johanson N, et al.Interleukin-12 is expressed by infiltrating macrophages and synovial lining cells in rheumatoid arthritis and osteoarthritis.Clin Diagn Lab Immunol.1998;5(4):430-437.
[21] Mullaji AB, Marawar S V, Luthm M. Tibial articular cartilage wear in varus osteoarthritic knees: correlation with anterior cruciate ligament integrity and severity of deformity. Arthroplasty.2008;23(1):128-135.
[22] Hnaghan J, Dieppe P.Study of 500 patients with limb joint osteoarthritis I Analysis by age, sex, and distribution of symptomatic joint sites.Ann Rheum Dis.1991,50(1): 8-13.
[23] Adebajo AO.Pattern of osteoarthritis in a west African teaching hospital. Ann Rheum Dis.1991;50(1):20-22.
[24] 申延清,刘风霞,曹红,等. 膝骨关节炎患者的临床表现及相关影响因素[J].中国组织工程研究与临床康复,2011,15(9): 1643-1646.
[25] 王梅,于长隆.老年骨性关节炎[J].中国临床康复, 2002,6(1): 25-27.
[26] Manchikanti L,Manchikanti KN, Cash KA, et al. Age-related prevalence of facet joint involvement in chronic neck and low back pain. Pain Physician.2008;11(1):67-75．
[27] 区广鹏,肖军,郑佐勇,等. 老年膝关节骨性关节炎患病危险因素的调查[J].中国组织工程研究, 2012,16(50):9463-9470.
[28] 王健,陶海荣. 雌激素及相关化合物干预骨关节炎作用机制:关节保护与骨软骨细胞的修复[J].中国组织工程研究, 2014, 18(33):5372-5376 .
[29] Lee YJ, Lee EB, Kwon YE, et al. Effect of estrogen on the expression of matrix metalloproteinase(MMP)-l, MMP-3,and MMP-13 and tissue inhibitor of metalloproternase-1 in osteoarthritis chondrocytes. Rheumatol Int.2003;23(6): 282-288．
[30] 黄家谷,夏春.雌激素与骨关节炎[J].中国老年学杂志, 2010, 30(24):3844-3846.
[31] 孙芙蓉,王丽.肥胖与骨关节炎关系的探讨[J].中外医学研究, 2013,11(22):147-148
[32] Suri P, Miyakoshi A, Hunter DJ, et al.Does lumbar spinal degeneration begin with the anterior structures? A study of the observed epidemiology in a community-based population. BMC Musculoskelet Disord. 2011;12:202.
[33] Trayhurn P,Wood IS.Signalling role of adipose tissue: adipokines and inflammation in obesity. Biochem Soc Trans. 2005;33(5):1078-1081．
[34] 李儒军,林剑浩.骨关节炎流行病学的研究进展[J].中国临床医生, 2010,38(7): 6-10.
[35] 吕厚山.现代人工关节学[M].北京:人民卫生出版社. 2006: 248- 250.
[36] Thomas JS,Gibson GE, Coordination and timing of spine and hip joints during full body reaching tasks.Hum Mov Sci.2007; 26(1):124-140.
[37] 吴海山.髋-脊柱综合征:髋关节发育不良诊治中不容忽视的问题[J].中华外科杂志,2008,17(46):1311-1313.
[38] Barrey C,Roussouly P,Perrin G,et al. Sagittal balance disorders in severe degenerative spine:can we identify the compensatory mechanisms.Eur Spine J.2011;20(Suppl 5): 626-633.
[39] Schwab F,Lafage V,Patel A,et al.Sagittal plane considerations and the pelvis in the pelvis in the adult patient.Spine.2009; 34(17):1828-1833.
[40] Simmons ED.Surgical Treatment of Patients With Lumbar Spinal Stenosis With Associated Scoliosis. Clin Orthop Relat Res. 2001;(384):45-53.
[41] Dubousset J.Three-dimensional analysis of the scoliotic deformity. In:Weinstein SL,ed.Pediatric Spine:Principles and Practice.New York,NY:Raven Press.1994.
[42] Pierre Roussouly.Biomechanical analysis of the spino-pelvic organization and adaptation in pathology.Eur Spine J.2011; 20(5):609-618.
[43] 程士欢,朱东,髋臼前倾和后倾的影像学及生物力学研究[J],实用骨科杂志,2010,16(2):109-113.
[44] During J,Goudfrooij H,Keessen W,et al.Towards standards for posture.Postural characteristics of the lower back system in normal and pathologic conditions.Spine.1985;10:83-87.
[45] Duval-Beaupere G,Schmidt C,Cosson P.A Baryeentremetric study of the sagittal shape of spine and pelvis:the conditions required for all econonlic standing position.Ann Biomed Engl. 1992; 20(4):451-462.
[46] Ferguson AB,The clinical and roentgenographic interpretation of lumbosacral anomalies.Radiology.1934;22:548-558.
[47] Mac-Thiong JM,Roussouly P,Berthonnaud E,et al.Sagittal parameters of global spinal balance:normative values from a prospective cohort of seven hundred nine Caucasian asymptomatic adults.Spine(Phila Pa 1976).2010;35(22): 1193-1198.
[48] Roussouly P,Pinheiro-Franco JL.Biomechanical analysis of the spino-pelvic organization and adaptation in pathology.Eur Spine J.2011;20(5):609-618.
[49] Marty C,Boisaubert B,Descamps H,et al.The sagittal anatomy of the sacrum among young adults,infants,and spondylolisthesis patients.Eur Spine.2002;11(2):119-125.
[50] Labelle H,Roussouly P,Berthonnaud E,et al. Spondylolisthesis,pelvic incidence,and spinopelvic balance:a correlation study.Spine.2004;29(18):2049-2054.
[51] Jackson RP,Phipps T,Hales C,et al.Pelvic lordosis and alignment in spondylolisthesis.Spine.2003;28(2):151-160.
[52] Gottfried ON, Daubs MD, Patel AA, et al.Spinopelvic parameters in postfusion flatback deformity patients. Spine J. 2009 Aug;9(8):639-647.
[53] Roussouly P, Gollogly S, Berthonnaud E, et al.Classification of the Normal Variation in the Sagittal Alignment of the Human Lumbar Spine and Pelvis in the Standing Position.Spine.2005; 30(3):346-353.
[54] Gardocki RJ, Watkins RG, Williams LA. Williams. Measurements of lumbopelvic lordosis using the pelvic radius technique as it correlates with sagittal spinal balance and sacral translation. Spine J. 2002;2(6):421-429.
[55] Schwab F,Lafage V,Patel A,et al.Sagittal plane considerations and the pelvis in the adult patient.Spine.2009;34(17):1828- 1833.
[56] Rajnics P,Templier A,Skalli W,et al.The importance of spinopelvic parameters in patients with lumbar disc lesions.Int Orthop.2002;26(2):104-108.
[57] McNcmara MJ,Barrett KG,Christie MJ,et al.Lumbar spinal stenosis and lower extremity arthroplasty.J Arthroplasty. 1993; 8(3):273-277.
[58] Lamartina C, Berjano P, Petruzzi M, et al．Criteria to restore the sagittal balance in deformity and degenerative spondylolisthesis. Eur Spine J.2012;21(1):27-31．
[59] Barrey C, Roussouly P, Perrin G,et al.Sagittal balance disorders in severe degenerative spine. Can we identify the compensatory mechanisms? Eur SPine J.2011;20( 5): 626-633．
[60] Duval-Beaupe’re G,Legaye J.Composante sagittale de la statique rachidienne.Rev Rhum.2004;71:105-119.
[61] Yoshimoto H,Sato S,Masuda T,et al.Spinopelvic alignment in patients with osteoarthrosis of the hip.Spine.2005; 30(14): 1650-1657.
[62] Troyanovich SJ,Cailliet R,Janik TJ,et al.Radiographic menstruation characteristicsof the sagittal lumbar spine from a normal population with a method to synthesize prior studies of lordosis.J Spinal Disord.1997;10(17):380-386.
