Correlation of knee joint alignment correction between valgus stress and postoperative radiography after unicompartmental knee arthroplasty

doi:10.12307/2023.615

Abstract

Abstract: BACKGROUND: Stress radiographs had a certain reference value for the correction of the lower limb alignment in unicompartmental knee arthroplasty, but the extent of tibiofemoral subluxation correction was still unclear. In addition, most medical centers did not pay enough attention to this examination.
OBJECTIVE: To clarify the correlation between the degree of correction of knee varus deformity and subluxation on the stress radiographs and the X-ray appearance after unicompartmental knee arthroplasty.
METHODS: We retrospectively analyzed the patients who undertook unicompartmental knee arthroplasty from January 2018 to January 2021. Totally 37 patients with 50 knees were included. The clinical outcome, and the radiographic assessment including the hip-knee-ankle angle, joint line convergence angle and coronal tibiofemoral subluxation value were assessed on pre- and post-operative full-length radiographs, as well as preoperative valgus stress radiographs. The correlations in-between these factors were analyzed.
RESULTS AND CONCLUSION: (1) Compared with preoperative radiographs, hip-knee-ankle angle, joint line convergence angle and coronal tibiofemoral subluxation were significantly corrected in valgus stress and postoperative radiographs (P < 0.05). (2) Pearson correlation analysis showed that the correction of joint line convergence angle on the valgus stress radiographs was positively correlated with the correction of hip-knee-ankle angle after unicompartmental knee arthroplasty (r=0.420, P < 0.05), while the correction of coronal tibiofemoral subluxation at valgus stress radiographs was also positively correlated with the correction of postoperative coronal tibiofemoral subluxation (r=0.754, P < 0.05). (3) Thus, unicompartmental knee arthroplasty can correct the varus deformity and coronal tibiofemoral joint subluxation of the knee joint, and the degree of correction can be effectively predicted by preoperative valgus stress radiographs.

Key words: uniconpartmental knee arthroplasty, valgus stress radiograph, coronal tibiofemoral subluxation, knee osteoarthritis, correlation analysis

CLC Number:

Li Shichao, Xie Guangyue, Sun Zhen, Han Peng, Hou Xiaohua, Sun Xiaowei, Zhang Qidong. Correlation of knee joint alignment correction between valgus stress and postoperative radiography after unicompartmental knee arthroplasty[J]. Chinese Journal of Tissue Engineering Research, 2023, 27(18): 2910-2914.

Figures/Tables 4

References

[1] CAMPI S, PAPALIA GF, ESPOSITO C, et al. Unicompartmental Knee Replacement in Obese Patients: A Systematic Review and Meta-Analysis. J Clin Med. 2021; 10(16):3594.
[2] DEMEY G, MÜLLER JH, LIEBENSTEINER M, et al. Insufficient evidence to confirm benefits of custom partial knee arthroplasty: a systematic review. Knee Surg Sports Traumatol Arthrosc. 2021 Nov 18. doi: 10.1007/s00167-021-06766-7. Online ahead of print.
[3] KYRIAKIDIS T, ASOPA V, BAUMS M, et al. Unicompartmental knee arthroplasty in patients under the age of 60 years provides excellent clinical outcomes and 10-year implant survival: a systematic review : A study performed by the Early Osteoarthritis group of ESSKA-European Knee Associates section. Knee Surg Sports Traumatol Arthrosc. 2022 Jun 28. doi: 10.1007/s00167-022-07029-9. Online ahead of print.
[4] RADHAKRISHNAN GT, MAGAN A, KAYANI B, et al. Return to Sport After Unicompartmental Knee Arthroplasty: A Systematic Review and Meta-analysis. Orthop J Sports Med. 2022;10(3):23259671221079285.
[5] SERSHON RA, FRICKA KB, HAMILTON WG, et al. Early Results of a Randomized Controlled Trial of Partial Versus Total Knee Arthroplasty. J Arthroplasty. 2022; 37(6S):S94-S97.
[6] SUN X, LIU P, LU F, et al. Bearing dislocation of mobile bearing unicompartmental knee arthroplasty in East Asian countries: a systematic review with meta-analysis. J Orthop Surg Res. 2021;16(1):28.
[7] 马尚,王上增.单室膝骨关节炎单髁与全膝置换术短期效果比较[J].中国矫形外科杂志,2021,29(15):1359-1363.
[8] 文涛,薛华明,马童.应力位片结合关节镜探查在单髁置换术中的应用[J].生物骨科材料与临床研究,2017,14(5):18-21.
[9] 张启栋,郭万首,岳聚安.术前外翻应力位X线片预测Oxford单髁关节置换术后下肢力线变化的临床研究[J].中国骨与关节杂志,2016,5(10):747-751.
[10] 王浩浩,张民,席刚.膝关节冠状位半脱位研究进展[J].中华关节外科杂志 (电子版),2020,14(6):747-751.
[11] KAMENAGA T, HIRANAKA T, HIDA Y, et al. Lateral osteoarthritis progression is associated with a postoperative residual tibiofemoral subluxation in Oxford UKA. Knee Surg Sports Traumatol Arthrosc. 2021 Sep 13. doi: 10.1007/s00167-021-06729-y.
[12] OGAWA H, MATSUMOTO K, AKIYAMA H. Coronal tibiofemoral subluxation is correlated to correction angle in medial opening wedge high tibial osteotomy. Knee Surg Sports Traumatol Arthrosc. 2018;26(11):3482-3490.
[13] ISHII Y, NOGUCHI H, SATO J, et al. Association between bone mineral density distribution and various radiographic parameters in patients with advanced medial osteoarthritis of the knee. J Orthop Sci. 2019;24(4):686-692.
[14] SIRIWANARANGSUN P, CHEN KC, FINKENSTAEDT T, et al. Patterns of cartilage degeneration in knees with medial tibiofemoral offset. Skeletal Radiol. 2019; 48(6):931-937.
[15] CERVERI P, BELFATTO A, MANZOTTI A. Predicting Knee Joint Instability Using a Tibio-Femoral Statistical Shape Model. Front Bioeng Biotechnol. 2020;8:253.
[16] SUN XW, LU FF, ZOU K, et al. Does new instrument for Oxford unicompartmental knee arthroplasty improve short-term clinical outcome and component alignment? A meta-analysis. J Orthop Surg Res. 2020;15(1):386.
[17] 孙晓威,张启栋,王卫国. 运动对线单髁膝置换的临床与影像研究[J].中国矫形外科杂志,2022,30(3):198-202.
[18] 孙晓威,柳昌全,黄诚.胫骨后倾角的改变与牛津活动衬垫单髁置换术中间隙压力及术后膝关节活动度的关系[J].中华医学杂志,2022,102(25):1904-1909.
[19] 张启栋,王卫国,郭万首.如何实现Oxford单髁置换的准确截骨和术后稳定[J].生物骨科材料与临床研究,2022,19(1):1-5.
[20] ZHANG Q, YUE J, WANG W, et al. FTFA change under valgus stress force radiography is useful for evaluating the correctability of intra-articular varus deformity in UKA. Arch Orthop Trauma Surg. 2018;138(7):1003-1009.
[21] NAM D, KHAMAISY S, GLADNICK BP, et al. Is tibiofemoral subluxation correctable in unicompartmental knee arthroplasty? J Arthroplasty. 2013;28(9):1575-1579.
[22] KHAMAISY S, NAM D, THEIN R, et al. Limb alignment, subluxation, and bone density relationship in the osteoarthritic varus knee. J Knee Surg. 2015;28(3):207-212.
[23] SCHADLER P, KASPAREK M, BOETTNER F, et al. Coronal tibiofemoral subluxation is not an independent risk factor for total knee arthroplasty in patients with moderate to severe varus-osteoarthritis: data from the “Osteoarthritis Initiative”. Arch Orthop Trauma Surg. 2017;137(10):1423-1428.
[24] KHAMAISY S, ZUIDERBAAN HA, THEIN R, et al. Coronal tibiofemoral subluxation in knee osteoarthritis. Skeletal Radiol. 2016;45(1):57-61.
[25] SPRINGER B, WALDSTEIN W, BECHLER U, et al. The Functional Status of the ACL in Varus OA of the Knee: The Association With Varus Deformity and Coronal Tibiofemoral Subluxation. J Arthroplasty. 2021;36(2):501-506.
[26] WANG D, WILLINGER L, ATHWAL KK, et al. Knee Joint Line Obliquity Causes Tibiofemoral Subluxation That Alters Contact Areas and Meniscal Loading. Am J Sports Med. 2021;49(9):2351-2360.
[27] BOETTNER F, SPRINGER B, WINDHAGER R, et al. The tibial spine sign does not indicate cartilage damage in the central area of the distal lateral femoral condyle. Knee Surg Sports Traumatol Arthrosc. 2020;28(8):2592-2597.
[28] BUYUKKUSCU MO, MISIR A, KIRAT A, et al. Tibiofemoral subluxation in the coronal plane does not affect WOMAC and KOOS after total knee arthroplasty. Knee Surg Sports Traumatol Arthrosc. 2021;29(3):914-920.
[29] GREIF DN, EPSTEIN AL, HODGENS BH, et al. Current Measurement Strategies of Coronal Tibiofemoral Subluxation: A Systematic Review of Literature. AJR Am J Roentgenol. 2021;216(5):1183-1192.
[30] KIM YT, CHOI JY, LEE JK, et al. Coronal tibiofemoral subluxation is a risk factor for postoperative overcorrection in high tibial osteotomy. Knee. 2019;26(4):832-837.
[31] AKAMATSU Y, OHNO S, KOBAYASHI H, et al. Coronal subluxation of the proximal tibia relative to the distal femur after opening wedge high tibial osteotomy. Knee. 2017;24(1):70-75.
