Biocompatibility of carbon fiber interbody fusion cage versus titanium mesh cage in treatment of lumbar disc degeneration

doi:10.3969/j.issn.2095-4344.2015.12.020

Abstract

Abstract:

BACKGROUND: The endplate can be combined closely with different intervertebral fusion cages through the pedicle screw internal fixation system, to provide a more reliable spine stability for reconstruction of intervertebral height, lumbar physiological curvature and biomechanical function.
OBJECTIVE: To compare the effectiveness of carbon fiber interbody fusion cage and titanium mesh cage in lumbar disc degeneration.
METHODS: Sixty patients with L3-S1 lumbar disc degeneration who underwent posterior lumbar interbody fusion, 33 males and 27 females, were randomized into carbon fiber interbody fusion cage group and titanium mesh cage group. Japanese Orthopaedic Association Scores were compared between the two groups before and after the implantation, as well as the intervertebral height, intervertebral fusion and complications.
RESULTS AND CONCLUSION: Sixty patients completed the 3-27 months follow-up, and had good bone fusion. Lumbar activity was normal in all the patients at 3 months after treatment. The Japanese Orthopaedic Association Scores at 3 months after implantation and the intervertebral height at 1 week after implantation were significantly improved in the two groups (P < 0.05), but there was no difference between the two groups. The materials in the two groups had good biocompatibility with no rejection and no infection. Fusion cage subsidence occurred in two cases from the titanium mesh cage group. These findings indicate that both of carbon fiber interbody fusion cage and titanium mesh cage have good biocompatibility, improve the stability of the vertebral body, and restore the intervertebral height. Moreover, the carbon fiber material performance is better than the metal titanium mesh because of lower complication rate.

中国组织工程研究杂志出版内容重点：生物材料；骨生物材料; 口腔生物材料; 纳米材料; 缓释材料; 材料相容性；组织工程

全文链接：

Key words: Spinal Fusion, Lumbar Vertebrae, Biocompatible Materials

CLC Number:

R318

Song Cheng-zhe, Jin Hong-xu. Biocompatibility of carbon fiber interbody fusion cage versus titanium mesh cage in treatment of lumbar disc degeneration[J]. Chinese Journal of Tissue Engineering Research, 2015, 19(12): 1909-1913.

Figures/Tables 2

2.1 受试者数量分析 60例患者均进入结果分析，无脱落。 2.2 随访情况随访3-27个月，平均13.8个月，行腰椎X射线正侧位和过伸过屈动力位片、CT检查等。 2.3 两组治疗前后的JOA评分、椎间高度及植骨融合比较两组治疗后的临床症状和神经功能障碍均得到不同程度改善，两组手术时间、术中出血量比较差异无显著性意义(P > 0.05)，JOA评分、椎间高度与治疗前比较明显改善(P < 0.05)，但两组间比较差异无显著性意义(P > 0.05)，见表1，2。所有患者经X射线等检查植骨融合良好，无明显神经压迫，均获得良好的融合率，融合器周围无透亮线，有骨小梁形成。融合时间平均为10.4个月，治疗后3个月患者腰部活动基本正常，较治疗前有明显改善。 2.4 两种融合器的材料生物相容性正常人体液的pH值是7.4，含有盐电解质和有机分子及细胞，可加快植入物的化学反应，钛合金由于表面生成致密稳定的钝化膜，置入腰椎后起到很强的抗腐蚀作用。钛合金还具有易加工性能、成本低廉等优点，生物相容性良好，融合器置入人体后炎症反应逐渐消失，长期观察无炎症反应，无排斥反应，无明显不良反应。钛合金具有一定的强度和刚度，可以即刻重建腰椎稳定性，促进骨性融合。新型的钛合金材料虽然在成分上有所改进，以达到降低材料弹性模量的作用，弹性模量在70-100 GPa，但仍然高于人体正常骨的3-20 GPa。碳纤维融合器完整的骨性结构增大上下椎体的骨融合面积，具有良好的生物相容性，接近人体骨弹性模量，具有满足临床需要的抗压强度，表面齿状突起不易脱落，碳纤维组未出现排异反应现象，无感染发生。 2.5 并发症随访发现钛网组2例出现下沉，发生时间在治疗后3-6个月，但并不影响手术疗效，也没有导致症状复发。由于碳纤维材料的抗压、刚度和弹性模量与人体皮质骨相似，碳纤维组未出现融合器下沉，无融合器移位，术后患者椎间高度得以恢复。 2.6 典型病例 56岁男性患者，因腰痛、右下肢酸痛跛行症状入院，诊断L4-5腰椎间盘突出，采用碳纤维椎间融合器行后路椎间融合，椎弓根钉系统辅助固定，术后患者症状完全缓解，恢复椎间高度，植骨融合良好，见图2。"

References

[1] Bydon M,De la Garza-Ramos R,Macki M,et al.Lumbar fusion versus nonoperative management for treatment of discogenic low back pain: a systematic review and meta-analysis of randomized controlled trials.J Spinal Disord Tech. 2014;27(5): 297-304.
[2] 于铁淼,苗会玲,靳宪辉,等.钛网融合器与自体髂骨植骨在胸腰椎爆裂骨折前路手术中的应用比较研究[J].中国骨与关节损伤杂志, 2013,28(3):210-212.
[3] 殷鹏,刘秀珍,吴延平,等.不同植骨材料在退变性腰椎病脊柱融合术中的应用与疗效比较[J].中国修复重建外科杂志,2012,26(7): 778-782.
[4] 袁振灿,郑燕平,刘新宇,等.不同植骨材料椎间融合效果的实验研究[J].山东大学学报:医学版,2008,46(3):276-279,283.
[5] Lawrence JP,Waked W,Gillon TJ,et al.rhBMP-2 (ACS and CRM formulations) overcomes pseudarthrosis in a New Zealand white rabbit posterolateral fusion model. Spine (Phila Pa 1976).2007;32(11):1206-1213.
[6] Schils F,Rilliet B,Payer M.Implantation of an empty carbon fiber cage or a tricortical iliac crest autograft after cervical discectomy for single-level disc herniation: a prospective comparative study. J Neurosurg Spine.2006;4(4):292-299.
[7] Bagby GW.Arthrodesis by the distraction-compression method using a stainless steel implant. Orthopedics.1988; 11(6):931-934.
[8] Kuslich SD,Danielson G,Dowdle JD,et al.Four-year follow-up results of lumbar spine arthrodesis using the Bagby and Kuslich lumbar fusion cage.Spine (Phila Pa 1976). 2000;25(20):2656-2662.
[9] Brantigan JW,Steffee AD,Geiger JM.A carbon fiber implant to aid interbody lumbar fusion. Mechanical testing.Spine (Phila Pa 1976).1991;16(6):S277-282.
[10] Ohtori S,Ito T,Yamashita M,et al. Evaluation of low back pain using the Japanese Orthopaedic Association Back Pain Evaluation Questionnaire for lumbar spinal disease in a multicenter study: differences in scores based on age, sex, and type of disease.J Orthop Sci.2010;15(1):86-91.
[11] Freeman BC,Licina P,Mehdian SH. Posterior lumbar interbody fusion combined with instrumented posterior-lateral fusion: 5-year results in 60 patients.J Bone Joint Surg Am. 2000; 81:572-586.
[12] 张立国,朱裕昌,徐玉良,等.退变腰椎不稳的诊断和治疗[J].中国脊柱脊髓杂志,2002,12(5):335.
[13] Ueno M,Imura T,Inoue G,et al.Posterior corrective fusion using a double-trajectory technique (cortical bone trajectory combined with traditional trajectory) for degenerative lumbar scoliosis with osteoporosis: technical note.J Neurosurg Spine. 2013;19(5):600-607.
[14] Schulz R,Melcher RP,Garib MC,et al.Does kyphotic deformity correlate with functional outcomes in fractures at the thoracolumbar junction treated by 360° instrumented fusion? Eur J Orthop Surg Traumatol.2014;24(1):S93-101.
[15] Lammli J,Whitaker MC,Moskowitz A,et al.Stand-alone anterior lumbar interbody fusion for degenerative disc disease of the lumbar spine: results with a 2-year follow-up.Spine (Phila Pa 1976).2014;39(15):E894-901.
[16] Kim DH,Jeong ST,Lee SS.Posterior lumbar interbody fusion using a unilateral single cage and a local morselized bone graft in the degenerative lumbar spine.Clin Orthop Surg.2009; 1(4):214-221.
[17] 丁悦,秦础强,黄东生,等.原位自体骨与同种异体骨混合移植在腰椎后外侧融合术中的应用[J].中国修复重建外科杂志,2009, 23(5):524-526.
[18] Ray CD.Threaded titanium cages for lumbar interbody fusions. Spine (Phila Pa 1976). 1997;22(6):667-680.
[19] Zhang JQ,Dong LQ,Jin CY,et al.Clinical control study in treating degenerative lumbar instability with single or double carbon fiber cages.Zhongguo Gu Shang.2009;22(10): 733-737.
[20] Lee HS,Lee JH,Lee JH.A comparison of dynamic views using plain radiographs and thin-section three-dimensional computed tomography in the evaluation of fusion after posterior lumbar interbody fusion surgery.Spine J.2013;13(10): 1200-1207.
[21] 郑安华,徐正生,方崇斌.椎弓根螺钉固定联合与非联合伤椎置钉治疗单节段胸腰椎骨折的对比研究[J].中医正骨,2012,24(12): 20-22.
[22] Zucherman JF,Zdeblick TA,Bailey SA,et al.Instrumented laparoscopic spinal fusion. Preliminary Results.Spine (Phila Pa 1976).1995;20(18):2029-2035.
[23] van der Haven I,van Loon PJ,Bartels RH,et al.Anterior cervical interbody fusion with radiolucent carbon fiber cages: clinical and radiological results.Acta Orthop Belg.2005; 71(5): 604-609.
[24] Kim SM,Rhee W,Ha S,et al.Influence of alendronate and endplate degeneration to single level posterior lumbar spinal interbody fusion.Korean J Spine. 2014;11(4):221-226.
[25] De la Garza-Ramos R,Bydon M,Abt NB,et al.The Impact of Obesity on Short- and Long-term Outcomes After Lumbar Fusion.Spine (Phila Pa 1976).2015;40(1):56-61.
[26] Bydon M,Macki M,De la Garza-Ramos R,et al.Smoking as an independent predictor of reoperation after lumbar laminectomy: a study of 500 cases.J Neurosurg Spine. 2015(2):1-6.
[27] Yoo M,Kim WH,Hyun SJ,et al.Comparison between Two Different Cervical Interbody Fusion Cages in One Level Stand-alone ACDF: Carbon Fiber Composite Frame Cage Versus Polyetheretherketone Cage.Korean J Spine.2014; 11(3):127-135.
[28] Bartels RH,Donk RD,Feuth T.Subsidence of stand-alone cervical carbon fiber cages. Neurosurgery. 2006;58(3): 502-508.
[29] Hasegawa K,Abe M,Washio T,et al.An experimental study on the interface strength between titanium mesh cage and vertebra in reference to vertebral bone mineral density. Spine (Phila Pa 1976).2001;26(8):957-963.
