Chinese Journal of Tissue Engineering Research ›› 2015, Vol. 19 ›› Issue (53): 8627-8632.doi: 10.3969/j.issn.2095-4344.2015.53.017

Previous Articles     Next Articles

Measurement and comparison of the digital anatomy of the tibia proximal part for the Han and Mongolian nationality

Zhang Zhi-feng1, Zhao Zhen-qun2, Huang Jian1, Hou Bo3, Wei Jing4, Wang Xing5, Zheng Lei-gang6

  1. 1Department of Joint Surgery, 2Department of Child Orthopaedics, 4Second Department of Hand and Foot Minimally Invasive Surgery, the Second Affiliated Hospital of Inner Mongoloa Medical University, Hohhot 010030, Inner Mongolia Autonomous Region, China; 3Fourth Department of Orthopaedics, Beijing Chaoyang Emergency Medical Center, Beijing 100000, China; 5Department of Human Anatomy, Basic Medical College of Inner Mongoloa Medical University, Hohhot 010059, Inner Mongolia Autonomous Region, China; 6Department of Orthopaedics, Inner Mongolia Autonomous Region Hospital of Traditional Chinese Medicine, Hohhot 010020, Inner Mongolia Autonomous Region, China
  • Received:2015-11-07 Online:2015-12-24 Published:2015-12-24
  • Contact: Huang Jian, M.D., Chief physician, Department of Joint Surgery, the Second Affiliated Hospital of Inner Mongoloa Medical University, Hohhot 010030, Inner Mongolia Autonomous Region, China
  • About author:Zhang Zhi-feng, Master, Attending physician, Department of Joint Surgery, the Second Affiliated Hospital of Inner Mongoloa Medical University, Hohhot 010030, Inner Mongolia Autonomous Region, China Zhao Zhen-qun, Master, Attending physician, Department of Child Orthopaedics, the Second Affiliated Hospital of Inner Mongoloa Medical University, Hohhot 010030, Inner Mongolia Autonomous Region, China Zhang Zhi-feng and Zhao Zhen-qun contributed equally to this work.
  • Supported by:

     the Natural Science Foundation of Inner Mongolia Autonomous Region, China, No. 2015MS0897

PDF

356

Cited

1

Abstract:

BACKGROUND: In the process of designing knee joint prosthesis and operating total knee arthroplasty for the Chinese people, we should not only take into account the proximal tibial anatomical characteristics and the difference of geometry, but also should pay attention to the differences between different races.
OBJECTIVE: To compare the anatomical morphological differences between Mongolian and Han nationality through measuring the CT tomography scanning and three-dimensional reconstruction measurement of tibia proximal part of Han and Mongolian nationality, so as to provide the data references for prosthesis selection used for total knee arthroplasty.
METHODS: Totally 60 patients who received the treatment at the Department of Joint Surgery were collected, and divided into Han nationality and Mongolian nationality groups (n=30/group, 15 males and 15 females in each group). The age was (36.00+7.22) years old. 16-row helical CT scan (American GE Lightspeed 16) was used for spiral scanning, slice thickness 0.625 mm. Scanning images were exported in DICOM format and saved. Digital three-dimensional reconstruction measurement was conducted using Mimics 15.0 three-dimensional reconstruction software. The tibial plateau width, anteroposterior diameter of the medial tibial plateau and lateral anteroposterior diameter were measured respectively to observe whether there were any differences among sex, sides and nationality.
RESULTS AND CONCLUSION: There were no significant differences in the above indicators between left and right sides (P > 0.05). There were significant differences in tibial plateau width, anteroposterior diameter of the medial tibial plateau and lateral anteroposterior diameter between males and females, and Han and Mongolian nationality groups (P < 0.05). Specific performed in: (1) There was significant difference in the morphological measurement parameters of proximal tibia between sex for Han and Mongolian nationality, and the mean value of male was larger compared with that of female. (2) There was certain significant difference in the part of the parameter indicators between Han and Mongolian nationality groups. These results suggest that the prosthesis should be chose and placed correctly according to the differences of morphological characteristics, gender, nationality, region of the Chinese people. (3) Digital three-dimensional reconstruction technology and individualized design can choose suitable prosthesis for different people, so as to ensure a good repair effect in patients after total knee replacement.

CLC Number:
