Anchors for the treatment of ankle fracture combined with deltoid ligament injury

doi:10.3969/j.issn.2095-4344.2013.39.024

Abstract

Abstract:

BACKGROUND: Ankle fracture combined with deltoid ligament injury can disorders the anatomical structure of ankle joint. Improper treatment can cause more serious complication, such as walking disorders.
OBJECTIVE: To evaluate the clinical effect of anchor repair plus open reduction internal fixation in the treatment of ankle fracture combined with deltoid ligament injury.
METHODS: Thirty-five patients with ankle fracture combined with deltoid ligament injury were selected from the Department of Orthopedics, the Sixth People’s Hospital Affiliated to Shanghai Jiao Tong University between May 2009 and January 2011, including 24 males and 11 females, and all the patients were treated with anchor repair plus open reduction internal fixation. The age of the patients was 22-61 years, averaged 35.7 years, and all the patients were closed injury without other fractures. The treatment time was 2-10 days, average 4.6 days. According to Lauge-Hansen classification, 26 patients had supination-eversion ankle fracture and nine patients had pronation-eversion. According to Danis-Weber classification, 26 patients were C type and nine patients were B type. After all the three patients were treated with anchor repair, the treatment effect of anchor repair was evaluated through assessing the improvement of clinical symptoms and signs, as well as the imaging examination of repair and healing.
RESULTS AND CONCLUSION: All the 35 patients were followed-up for 9-26 months, average 13.8 months. All the patients got Ⅰ stage healing without complications of infection and screw loosening. Follow-up X-ray film showed all the 35 patients with ankle fracture achieved bone union, the healing time was 10-21 weeks, average 13.6 weeks. Modified Baird-Jackson score system showed excellent in 11 cases, good in nine cases, average in four cases, poor in one case, and the excellent and good rate was 85.7%. At 6 months after internal fixation, the stress X-ray film examination showed the malleolus gap of the affect side was (3.49±0.36) mm, the malleolus gap of the healthy side was (3.37±0.41) mm, and there was no significant difference (P > 0.05). The results indicate anchor in the repair of deltoid ligament injury during the treatment of ankle fracture with open reduction internal fixation can achieve satisfactory therapeutic effect.

Key words: fractures, closed, fibula, tibia, ligaments, articular

CLC Number:

R318

Su Yan, Song Sa, Shen Long-xiang, Luo Cong-feng, Zhang Chang-qing, Zeng Bing-fang. Anchors for the treatment of ankle fracture combined with deltoid ligament injury[J]. Chinese Journal of Tissue Engineering Research, 2013, 17(39): 7015-7020.

Figures/Tables 3

References

[1]楼永坚,陈红卫.踝关节骨折的治疗进展[J].医学综述,2012, 18(19):3248-3251.
[2]Lloyd J, Elsayed S, Hariharan K, et al. Revisiting the concept of talar shift in ankle fractures. Foot Ankle Int. 2006; 27(10): 793-796.
[3]范磊,邵增务.踝关节骨折的分型和治疗进展[J].实用骨科杂志, 2008,14(5):317-320.
[4]吴在德.外科学[M].北京:人民卫生出版社,2000:889-892.
[5]Stufkens SA, Knupp M, Lampert C, et al. Long-term outcome after supination-external rotation type-4 fractures of the ankle. J Bone Joint Surg Br. 2009;91(12):1607-1611.
[6]Gérard R, Unno-Veith F, Fasel J, et al. The effect of collateral ligament release on ankle dorsiflexion: an anatomical study. Foot Ankle Surg. 2011;17(3):193-196.
[7]王旭,马昕,张超,等.三角韧带损伤在旋后-外旋型踝关节骨折治疗中的意义[J].中国骨与关节外科,2012,5(4):315-319.
[8]Schepull T, Kvist J, Aspenberg P. Early E-modulus of healing Achilles tendons correlates with late function: similar results with or without surgery. Scand J Med Sci Sports. 2012;22(1): 18-23.
[9]Lynch SA, Renström PA. Treatment of acute lateral ankle ligament rupture in the athlete. Conservative versus surgical treatment. Sports Med. 1999;27(1):61-71.
[10]Kristensen KD, Hansen T. Closed treatment of ankle fractures. Stage II supination-eversion fractures followed for 20 years. Acta Orthop Scand. 1985;56(2):107-109.
[11]Davidovitch RI, Egol KA. The medial malleolus osteoligamentous complex and its role in ankle fractures. Bull NYU Hosp Jt Dis. 2009;67(4):318-324.
[12]Haddad SL, Dedhia S, Ren Y, et al. Deltoid ligament reconstruction: a novel technique with biomechanical analysis. Foot Ankle Int. 2010;31(7):639-651.
[13]Low CK, Pang HY, Wong HP, et al. A retrospective evaluation of operative treatment of ankle fractures. Ann Acad Med Singapore. 1997;26(2):172-174.
[14]Low YP. Treatment of ankle fractures. Singapore Med J. 1995; 36(2):136-137.
[15]Naeder H, Dominik MC, Patrick V, et al. The posterolateral approach for the treatment of trimalleolar fractures. Foot Ankle Surg, 2007, 6(1): 44-49.
[16]Baird RA, Jackson ST. Fractures of the distal part of the fibula with associated disruption of the deltoid ligament. Treatment without repair of the deltoid ligament. J Bone Joint Surg Am. 1987;69(9):1346-1352.
[17]Park SS, Kubiak EN, Egol KA, et al. Stress radiographs after ankle fracture: the effect of ankle position and deltoid ligament status on medial clear space measurements. J Orthop Trauma. 2006;20(1):11-18.
[18]Gill JB, Risko T, Raducan V, et al. Comparison of manual and gravity stress radiographs for the evaluation of supination-external rotation fibular fractures. J Bone Joint Surg Am. 2007;89(5):994-999.
[19]Hintermann B, Knupp M, Pagenstert GI. Deltoid ligament injuries: diagnosis and management. Foot Ankle Clin. 2006; 11(3):625-637.
[20]Stark E, Tornetta P 3rd, Creevy WR. Syndesmotic instability in Weber B ankle fractures: a clinical evaluation. J Orthop Trauma. 2007;21(9):643-646.
[21]Sasse M, Nigg BM, Stefanyshyn DJ. Tibiotalar motion--effect of fibular displacement and deltoid ligament transection: in vitro study. Foot Ankle Int. 1999;20(11):733-737.
[22]Goeminne S, Debeer P. Delayed migration of a metal suture anchor into the glenohumeral joint. Acta Orthop Belg. 2010; 76(6):834-837.
[23]DeAngelis NA, Eskander MS, French BG. Does medial tenderness predict deep deltoid ligament incompetence in supination-external rotation type ankle fractures? J Orthop Trauma. 2007;21(4):244-247.
[24]Henari S, Banks LN, Radovanovic I, et al. Ultrasonography as a diagnostic tool in assessing deltoid ligament injury in supination external rotation fractures of the ankle. Orthopedics. 2011;34(10):e639-643.
