Locking plate fixation repairs lateral compression rotationally unstable pelvic ring injuries: reconstruction of pelvic stability

doi:10.3969/j.issn.2095-4344.2015.48.012

Abstract

Abstract:

BACKGROUND: There are still some controversies about lateral compression rotationally unstable pelvic ring injuries and fixed mode.
OBJECTIVE: To evaluate the pelvic stability of locking plate fixation pelvic reconstruction repairing lateral compression rotationally unstable pelvic ring injuries.
METHODS: We retrospectively analyzed 15 patients with unstable lateral compression rotationally unstable pelvic ring injuries treated with reconstruction locking plates fixation at Suzhou Xiangcheng People’s Hospital between November 2011 and November 2014. The Matta standard was used to evaluate the quality of fracture reduction. Clinical efficacy was evaluated by Majeed score.
RESULTS AND CONCLUSION: Fifteen patients were followed up for 12-44 months (mean 24 months). According to the standard of Matta, 11 cases were excellent, 2 cases were good, 2 cases were average, 0 case poor, and the excellent and good rate was 87%. According to Majeed functional assessment, clinical function outcomes were graded as 9 cases excellent, 3 cases good, 1 case average, 1 case poor; excellent and good rate was 80%. There were no patient loss of reduction and internal fixation failure among these 15 patients in the final follow-up. No iatrogenic neurovascular injury occurred. Incision superficial infection was detected in 2 patients with a Morel-Lavallee lesion after subjecting to double-tube continuous negative pressure drainage, and
healed after wound management. A large area of infection and skin necrosis did not occur. These results confirm that pelvic universal reconstruction locking plates in repair of lateral compression rotationally unstable pelvic ring injuries can maintain a strong and effective fixation. We should pay much attention to the cases of pelvic fractures combined with soft tissue injury around the pelvis.

中国组织工程研究杂志出版内容重点：人工关节；骨植入物；脊柱；骨折；内固定；数字化骨科；组织工程

CLC Number:

R318

Jian Zheng-guang, Xu Yun, Shi Yong, Tao Wei-jian, Ouyang Lin-zhi, Sun Xue-feng, Tang Tian-si. Locking plate fixation repairs lateral compression rotationally unstable pelvic ring injuries: reconstruction of pelvic stability[J]. Chinese Journal of Tissue Engineering Research, 2015, 19(48): 7776-7783.

Figures/Tables 3

References

[1] Young JW, Burgess AR, Brumback RJ, et al. Lateral compression fractures of the pelvis: the importance of plain radiographs in the diagnosis and surgical management. Skeletal Radiol. 1986;15:103-109.

[2] 贾健.骨盆骨折的分类及内固定治疗[J].中华骨科杂志,2002, 22(11):695-698.

[3] Miranda MA, Riemer BL, Butterfield SL, et al. Pelvic ringinjuries: a long term functional outcome study. Clin Orthop Relat Res. 1996;(329):152-159.

[4] Weaver MJ, Bruinsma W, Toney E, et al. What are the patterns of injury and displacement seen in lateral compression pelvic fractures? Clin Orthop Relat Res. 2012; 470(8):2104-2110.

[5] Hoffmann MF, Jones CB, Sietsema DL. Persistent impairment after surgically treated lateral compression pelvic injury. Clin Orthop Relat Res. 2012;470(8):2161-2172.

[6] 胡昊,蔡林,金伟,等.外固定架联合髂腰固定术治疗垂直不稳定型骨盆骨折[J].中华骨科杂志,2011,31(1):61-65.

[7] Gardner MJ, Nork SE. Stabilization of unstable pelvic fractures with supraacetabular compression external fixation. J Orthop Trauma. 2007;21(4):269-273.

[8] Hao T, Changwei Y, Qiulin Z. Treatment of posterior pelvic ring injuries with minimally invasive percutaneous plate osteosynthesis. Int Orthop. 2009;33(5):1435-1439.

[9] 曹奇勇,王满宜,吴新宝,等.前路跨骶髂钢板固定治疗骨盆后环损伤[J].中华医学杂志, 2008,88(13):898-900.

[10] 夏平光,陈庄洪,蔡贤华,等.前路钢板螺钉内固定治疗骶髂关节分离损伤[J].中华创伤骨科杂志,2005,7(7):694-695.

[11] Suzuki T, Hak DJ, Ziran BH, et al. Outcome and complications of posterior transiliac plating for vertically unstable sacral fractures. Injury. 2009;40(4):405-409.

[12] 赵勇,邹德鑫,孙涛,等.加长骶髂螺钉和普通骶髂螺钉治疗单侧骶骨骨折的生物力学比较[J].中华创伤杂志,2014,30(7):730-734.

[13] Khaled SA, Soliman O, Wahed MA. Functional outcome of unstable pelvic ring injuries after iliosacral screw fixation: single versus two screw fixation. Eur J Trauma Emerg Surg. 2015;41(4):387-392.

[14] Senkowski CK, McKenney MG. Trauma scoring systems: a review. J Am Coll Surg. 1999;189(5):491-503.

[15] Day AC, Kinmont C, Bircher MD, et al. Crescent fracture-dislocation of the sacroiliac joint: a functional classification. J Bone Joint Surg Br. 2007;89(5):651-658.

[16] Logan C, Hess A, Kwon JY. Damage control orthopaedics: variability of construct design for external fixation of the lower extremity and implications on cost. Injury. 2015;46(8): 1533-1538.

[17] Matta JM, Tornetta P 3rd. Internal fixation of unstable pelvic ring injuries. Clin Orthop Relat Res. 1996;(329):129-140.

[18] Majeed SA. Grading the outcome of pelvic fractures. J Bone Joint Surg Br. 1989;71(2):304-306.

[19] Young JW, Burgess AR, Brumback RJ, et al. Pelvic fractures: value of plain radiography in early assessment and management. Radiology. 1986;160(2):445-451.

[20] Sagi HC, Papp S. Comparative radiographic and clinical outcome of two-hole and multi-hole symphyseal plating. J Orthop Trauma. 2008;22(6):373-378.

[21] Hamad A, Pavlou G, Dwyer J, et al. Management of pubic symphysis diastasis with locking plates: a report of 11 cases. Injury. 2013;44(7):947-951.

[22] Moed BR, O'Boynick CP, Bledsoe JG. Locked versus standard unlocked plating of the symphysis pubis in a Type-C pelvic injury: a cadaver biomechanical study. Injury. 2014; 45(4):748-751.

[23] 秦晖,安智全,姜朝来.经前侧入路手术治疗骨盆新月型骨折[J].中国修复重建外科杂志, 2011,25(7):816-820.

[24] Ragnarsson B, Oierud C, Olerud S. Anterior square-plate fixation of sacroiliac disruption: 2-8 years follow-up 0f 23 consecutive patients. Aeta Orthop Stand. 1993,64(2): 138-142.

[25] 殷小军,周正明,顾家烨,等.万向锁定钢板与重建钢板内固定治疗不稳定骨盆骨折的比较研究[J].中华创伤骨科杂志,2014, 16(12): 1099-1101.

[26] Suzuki T, Smith WR, Hak DJ, et al. Combined injuries of the pelvis and acetabulum: nature of a devastating dyad. J Orthop Trauma. 2010;24(5):303-308
