A serum-free monolayer method for differentiation of porcine induced pluripotent stem cells into vascular endothelial cells

doi:10.3969/j.issn.2095-4344.2115

Abstract

Abstract:

BACKGROUND: Induced pluripotent stem cells are a cell source with multiple differentiation potentials. Since pig is a suitable model for human cardiovascular and metabolic diseases, induction of porcine pluripotent stem cells into endothelial cells will provide a support for creating a porcine cardiovascular disease model.

OBJECTIVE: To establish a serum-free single layer culture method to induce porcine induced pluripotent stem cells into CD31 positive endothelial cells and to identify the obtained endothelial cells.

METHODS: We used the serum-free single layer culture method to induce porcine pluripotent stem cells and human embryonic stem cells into endothelial cells under different combinations of CHIR99021, bone morphogenetic protein 4, basic fibroblast growth factor and vascular endothelial growth factor through three stages. The expressions of germ layer markers of the two kinds of stem cells during their differentiation were detected and compared. The endothelial cells obtained after the flow sorting were identified.

RESULTS AND CONCLUSION: The endothelial cells differentiated from porcine induced pluripotent stem cells by a single layer culture method showed comparable morphological and functional properties to the immortalized porcine aortic endothelial cells, capable of taking up low-density lipoprotein and forming microvascular-like structure on matrigel. We found that the differentiation efficiency of porcine pluripotent stem cells was higher than that of human embryonic stem cells using the same method, which may be associated with the different expression patterns of lineage-specific markers in the two kinds of cells during the early differentiation.

Key words: porcine, induced pluripotent stem cell, differentiation, endothelial cell, human embryonic stem cells

CLC Number:

Wei Renyue, Li Xuechun, Li Yan, Yu Yang, Zhang Yu, Liu Zhonghua. A serum-free monolayer method for differentiation of porcine induced pluripotent stem cells into vascular endothelial cells[J]. Chinese Journal of Tissue Engineering Research, 2020, 24(31): 4971-4978.

Figures/Tables 5

References

[1] PIĄTEK J, KĘDZIORA A, KONSTANTY-KALANDYK J, et al. Coronary Artery Disease in Young Adults: Who Needs Surgical Revascularization? A Retrospective Cohort Study. Heart Surg Forum. 2016;19(4):E170-174.

[2] TAKAHASHI K, YAMANAKA S. Induction of pluripotent stem cells from mouse embryonic and adult fibroblast cultures by defined factors. Cell. 2006;126(4):663-676.

[3] ZHAO XY, LI W, LV Z, et al. iPS cells produce viable mice through tetraploid complementation. Nature. 2009;461(7260):86-90.

[4] TAKAHASHI K, TANABE K, OHNUKI M, et al. Induction of pluripotent stem cells from adult human fibroblasts by defined factors. Cell. 2007; 131(5):861-872.

[5] YU J, VODYANIK MA, SMUGA-OTTO K, et al. Induced pluripotent stem cell lines derived from human somatic cells. Science. 2007; 318(5858):1917-1920.

[6] TAURA D, SONE M, HOMMA K, et al. Induction and isolation of vascular cells from human induced pluripotent stem cells--brief report. Arterioscler Thromb Vasc Biol. 2009;29(7):1100-1103.

[7] CHOI KD, YU J, SMUGA-OTTO K, et al. Hematopoietic and endothelial differentiation of human induced pluripotent stem cells. Stem Cells. 2009;27(3):559-567.

[8] NG ES, DAVIS R, STANLEY EG, et al. A protocol describing the use of a recombinant protein-based, animal product-free medium (APEL) for human embryonic stem cell differentiation as spin embryoid bodies. Nat Protoc. 2008;3(5):768-776.

[9] NOURSE MB, HALPIN DE, SCATENA M, et al. VEGF induces differentiation of functional endothelium from human embryonic stem cells: implications for tissue engineering. Arterioscler Thromb Vasc Biol. 2010;30(1):80-89.

[10] LIPPMANN ES, AZARIN SM, KAY JE, et al. Derivation of blood-brain barrier endothelial cells from human pluripotent stem cells. Nat Biotechnol. 2012;30(8):783-791.

[11] HARDING A, CORTEZ-TOLEDO E, MAGNER NL, et al. Highly Efficient Differentiation of Endothelial Cells from Pluripotent Stem Cells Requires the MAPK and the PI3K Pathways. Stem Cells. 2017;35(4): 909-919.

[12] LUNNEY JK. Advances in swine biomedical model genomics. Int J Biol Sci. 2007;3(3):179-184.

[13] WU Z, CHEN J, REN J, et al. Generation of pig induced pluripotent stem cells with a drug-inducible system. J Mol Cell Biol. 2009;1(1): 46-54.

[14] EZASHI T, TELUGU BP, ALEXENKO AP, et al. Derivation of induced pluripotent stem cells from pig somatic cells. Proc Natl Acad Sci U S A. 2009;106(27):10993-10998.

[15] CHENG D, GUO Y, LI Z, et al. Porcine induced pluripotent stem cells require LIF and maintain their developmental potential in early stage of embryos. PLoS One. 2012;7(12):e51778.

[16] WANG J, GU Q, HAO J, et al. Tbx3 and Nr5α2 play important roles in pig pluripotent stem cells. Stem Cell Rev Rep. 2013;9(5):700-708.

[17] LI X, SHAN ZY, WU YS, et al. Generation of neural progenitors from induced Bama miniature pig pluripotent cells. Reproduction. 2013; 147(1):65-72.

[18] GU M, NGUYEN PK, LEE AS, et al. Microfluidic single-cell analysis shows that porcine induced pluripotent stem cell-derived endothelial cells improve myocardial function by paracrine activation. Circ Res. 2012;111(7):882-893.

[19] ALMALKI SG, AGRAWAL DK. ERK signaling is required for VEGF-A/VEGFR2-induced differentiation of porcine adipose-derived mesenchymal stem cells into endothelial cells. Stem Cell Res Ther. 2017;8(1):113.

[20] ALMALKI SG, LLAMAS VALLE Y, et al. MMP-2 and MMP-14 Silencing Inhibits VEGFR2 Cleavage and Induces the Differentiation of Porcine Adipose-Derived Mesenchymal Stem Cells to Endothelial Cells. Stem Cells Transl Med. 2017;6(5):1385-1398.

[21] SCHLEGEL F, APPLER M, HALLING M, et al. Reprogramming Bone Marrow Stem Cells to Functional Endothelial Cells in a Mini Pig Animal Model. Med Sci Monit Basic Res. 2017;23:285-294.

[22] YUSUF S, HAWKEN S, OUNPUU S, et al. Effect of potentially modifiable risk factors associated with myocardial infarction in 52 countries (the INTERHEART study): case-control study. Lancet. 2004; 364(9438):937-952.

[23] HEIDENREICH PA, TROGDON JG, KHAVJOU OA, et al. Forecasting the future of cardiovascular disease in the United States: a policy statement from the American Heart Association. Circulation. 2011; 123(8):933-944.

[24] WRITING GROUP MEMBERS, MOZAFFARIAN D, BENJAMIN EJ, et al. Heart Disease and Stroke Statistics-2016 Update: A Report From the American Heart Association. Circulation. 2016;133(4):e38-360.

[25] BAI H, XIE YL, GAO YX, et al. The balance of positive and negative effects of TGF-β signaling regulates the development of hematopoietic and endothelial progenitors in human pluripotent stem cells. Stem Cells Dev. 2013;22(20):2765-2776.

[26] DROWLEY L, KOONCE C, PEEL S, et al. Human Induced Pluripotent Stem Cell-Derived Cardiac Progenitor Cells in Phenotypic Screening: A Transforming Growth Factor-β Type 1 Receptor Kinase Inhibitor Induces Efficient Cardiac Differentiation. Stem Cells Transl Med. 2016; 5(2):164-174.

[27] COCHRANE A, KELAINI S, TSIFAKI M, et al. Quaking Is a Key Regulator of Endothelial Cell Differentiation, Neovascularization, and Angiogenesis. Stem Cells. 2017;35(4):952-966.

[28] WHITE MP, RUFAIHAH AJ, LIU L, et al. Limited gene expression variation in human embryonic stem cell and induced pluripotent stem cell-derived endothelial cells. Stem Cells. 2013;31(1):92-103.

[29] ORLOVA VV, VAN DEN HIL FE, PETRUS-REURER S, et al. Generation, expansion and functional analysis of endothelial cells and pericytes derived from human pluripotent stem cells. Nat Protoc. 2014;9(6):1514-1531.

[30] YING QL, WRAY J, NICHOLS J, et al. The ground state of embryonic stem cell self-renewal. Nature. 2008;453(7194):519-523.

[31] BUEHR M, MEEK S, BLAIR K, et al. Capture of authentic embryonic stem cells from rat blastocysts. Cell. 2008;135(7):1287-1298.

[32] ZHANG P, LI J, TAN Z, et al. Short-term BMP-4 treatment initiates mesoderm induction in human embryonic stem cells. Blood. 2008; 111(4):1933-1941.

[33] LU TY, LIN B, KIM J, et al. Repopulation of decellularized mouse heart with human induced pluripotent stem cell-derived cardiovascular progenitor cells. Nat Commun. 2013;4:2307.

[34] SIL S, PERIYASAMY P, THANGARAJ A, et al. PDGF/PDGFR axis in the neural systems. Mol Aspects Med. 2018;62:63-74.

[35] LEBLEU VS, TADURI G, O'CONNELL J, et al. Origin and function of myofibroblasts in kidney fibrosis. Nat Med. 2013;19(8):1047-1053.

[36] MIWA H, ERA T. Mesoderm Differentiation from hiPS Cells. Methods Mol Biol. 2016;1357:403-413.

[37] IWAI K, ISHIKURA H, INOUE T, et al. A case of AFP-positive pancreas papillary carcinoma suggestive of a primitive endoderm phenotype. Acta Pathol Jpn. 1993;43(7-8):434-439.

[38] VIOTTI M, NOWOTSCHIN S, HADJANTONAKIS AK. Afp::mCherry, a red fluorescent transgenic reporter of the mouse visceral endoderm. Genesis. 2011;49(3):124-133.

[39] ABACI HE, GUO Z, COFFMAN A, et al. Human Skin Constructs with Spatially Controlled Vasculature Using Primary and iPSC-Derived Endothelial Cells. Adv Healthc Mater. 2016;5(14):1800-1807.

[40] GIACOMELLI E, BELLIN M, SALA L, et al. Three-dimensional cardiac microtissues composed of cardiomyocytes and endothelial cells co-differentiated from human pluripotent stem cells. Development. 2017;144(6):1008-1017.

[41] HOMMA K, SONE M, TAURA D, et al. Sirt1 plays an important role in mediating greater functionality of human ES/iPS-derived vascular endothelial cells. Atherosclerosis. 2010;212(1):42-47.

[42] BAO X, LIAN X, PALECEK SP. Directed Endothelial Progenitor Differentiation from Human Pluripotent Stem Cells Via Wnt Activation Under Defined Conditions.Methods Mol Biol. 2016;1481:183-196.

[43] ZHANG F, WANG L, LI Y, et al. Optimizing mesoderm progenitor selection and three-dimensional microniche culture allows highly efficient endothelial differentiation and ischemic tissue repair from human pluripotent stem cells. Stem Cell Res Ther. 2017;8(1):6.
