Feasibility of vertebral CT value in differentiating fresh and old osteoporotic vertebral compression fractures

doi:10.12307/2023.310

Abstract

Abstract: BACKGROUND: The incidence of osteoporotic vertebral compression fracture is increasing year by year. Clinical differentiation of fresh or old fractures determines the choice of treatment for patients. It is of great clinical significance to find a simple and rapid method to identify the properties of osteoporotic vertebral compression fracture in hospitals without relevant examination facilities and in patients with contraindications to MRI and single photon emission computed tomography whole-body bone scanning.
OBJECTIVE: To analyze and compare the consistency between vertebral CT values (Hounsfield units value, HU) and MRI in differentiating fresh and old osteoporotic vertebral compression fractures and to explore the feasibility of using vertebral CT values to diagnose fresh osteoporotic vertebral compression fractures.
METHODS: A retrospective analysis was performed on 40 patients, aged 55-89 (74.63±9.71) years, diagnosed as osteoporotic vertebral compression fracture with complete MRI and CT examination in Dongzhimen Hospital Affiliated to Beijing University of Traditional Chinese Medicine from January 2018 to October 2021. The nature of vertebral fractures was determined based on MRI images: Diagnostic criteria of fresh osteoporotic vertebral compression fracture based on MRI were high signal intensity of bone marrow edema on fat-suppression images, whereas normal signal of MRI on the vertebral body with wedge-shaped was diagnosed as old osteoporotic vertebral compression fracture. The vertebral CT values of target vertebrae with its adjacent level were measured separately. The CT value of target vertebra significantly higher than adjacent vertebra was diagnosed as fresh osteoporotic vertebral compression fracture but similar CT value as old osteoporotic vertebral compression fracture. Wilcoxon rank-sum test was used to compare the consistency of fresh and old vertebral fractures determined by MRI and vertebral CT values.
RESULTS AND CONCLUSION: (1) A total of 55 vertebral bodies were involved in 40 patients; 42 fresh fractures and 13 old fractures were diagnosed via MRI. (2) The Hu of fresh fractured osteoporotic vertebral compression fracture vertebral body (139.99±49.69 HU) was significantly higher than that of normal adjacent vertebral body (60.44 ±34.74 HU) (P < 0.01). The Hu of old fractured vertebral body (55.65±31.31 HU) was 6.19 HU (1.09-14.51 HU) from that of normal adjacent vertebral body (55.07±29.47 HU), and there was no statistical difference (P > 0.05). (3) The vertebral body CT value was used to diagnose 41 fresh fractured vertebral bodies and 14 old fractured vertebral bodies. (4) Wilcoxon rank-sum test showed that MRI and CT were highly consistent in differentiating fresh and old fractures in osteoporotic vertebral compression fracture (Kappa value=0.951). (5) It is concluded that the CT has high consistency with MRI in differentiating fresh and old fracture of osteoporotic vertebral compression fracture. By comparing the CT values of the target and adjacent vertebrae, fresh or old fractures can be accurately distinguished, which can provide a simple examination method other than MRI for rapid clinical decision making. For fractures that are difficult to determine, the combination of vertebral CT values and MRI can markedly improve the diagnostic accuracy.

Key words: vertebral CT value, osteoporotic vertebral fracture, fresh fracture, old fracture

CLC Number:

Feng Ningning, Jiang Guozheng, Yu Xing, Zhao He, Yang Yongdong, Guan Jianbin, Ma Yukun, Wang Shuyang. Feasibility of vertebral CT value in differentiating fresh and old osteoporotic vertebral compression fractures[J]. Chinese Journal of Tissue Engineering Research, 2023, 27(18): 2892-2896.

Figures/Tables 3

References

[1] 高健安,陈曦,张隆盛,等.经皮椎体后凸成形过程中脊柱植入物的种类及优势[J].中国组织工程研究,2020,24(12):1935-1940.
[2] 唐向盛,谭明生,移平,等.椎体后凸成形术治疗伴有肋间痛的胸椎压缩性骨折的临床疗效分析[J].中国骨伤,2017,30(9):823-827.
[3] 刘业成,王松松,董金鑫,等.核磁共振成像(MRI)在骨质疏松性椎体压缩骨折诊断中的作用探究[J].航空航天医学杂志,2022,33(4):394-397.
[4] ZAIDI Q, DANISA OA, CHENG W. Measurement techniques and Utility of Hounsfield unit values for assessment of bone quality prior to spinal instrumentation: a review of current literature. Spine(Phila Pa 1976). 2019;44(4):E239-E244.
[5] FAZEKAS F, CHAWLUK JB, ALAVI A, et al. MR signal abnormalities at 1.5T in Alzheimer’s dementia and normal aging. AJR Am J Roentgenol. 1987;149(2):351-356.
[6] BREDOW J, BOESE CK, WERNER CM, et al. Predictive validity of preoperative CT scans and the risk of pedicle screw loosening in spinal surgery. Arch Orthop Trauma Surg. 2016;136(8):1063-1067.
[7] 邹达,李危石,陈仲强,等.椎体CT值在腰椎短节段内固定术后螺钉松动预测中的应用[J].中国脊柱脊髓杂志,2018,28(5):447-455.
[8] 周晶,周蕾,刘超,等.椎体CT值预测单纯斜外侧腰椎间融合术后融合器下沉[J].中国修复重建外科杂志,2021,35(11):1449-1456.
[9] 刘云,李培岭,郭永杰,等.中老年骨质疏松症患者腰1-3椎体骨密度值与CT值相关性研究[J].风湿病与关节炎,2021,10(6):29-31.
[10] 来卫忠,张红霞,秦晓峰,等.椎体松质骨CT值测量在诊断骨质疏松中的应用价值分析[J].实用医技杂志,2021,28(6):772-774.
[11] 姚倩倩,李娟,朱春雨,等.胸腰段椎体CT值对骨质疏松骨折预测意义[J].中国矫形外科杂志,2021,29(10):943-946.
[12] 刘姣姣,于希越,秦健.椎体CT值筛查骨质疏松及预测骨折的研究进展[J].中国骨质疏松杂志,2022,28(1):129-133.
[13] SCHREIBER JJ, ANDERSON PA, ROSAS HG, et al. Hounsfield units for assessing bone mineral density and strength: a tool for osteoporosis management. J Bone Joint Surg Am. 2011;93(11):1057-1063.
[14] ZOU D, MUHEREMU A, SUN Z, et al. Computed tomography Hounsfield unit-based prediction of pedicle screw loosening after surgery for degenerative lumbar spine disease. J Neurosurg Spine. 2020;1 -6. doi: 10.3171/2019.11. SPINE19868.
[15] 杨惠林,刘强,唐海.重视我国骨质疏松性椎体压缩骨折的规范化诊疗[J].中华医学杂志,2016,96(48):3857-3861.
[16] GEHLBACH S, SAAG KG, ADACHI JD, et al. Previous fractures at multiple sites increase the risk for subsequent fractures: the Global Longitudinal Study of Osteoporosis in Women. J Bone Miner Res. 2012;27(3):645-653.
[17] HUANG YS, HAO DJ, FENG H, et al. Comparison of percutaneous kyphoplasty and bone cement-augmented short-segment pedicle screw fixation for management of kummell disease. Med Sci Monit. 2018;24:1072-1079.
[18] GAITANIS IN, HADJIPAVLOU AG, KATONIS PG, et al. Balloon kyphoplasty for the treatment of pathological vertebral compressive fractures. Eur Spine J. 2005; 14(3):250-260.
[19] BAUR A, STÄBLER A, ARBOGAST S, et al. Acute osteoporotic and neoplastic vertebral compression fractures: fluid sign at MR imaging. Radiology. 2002;225(3):730-735.
[20] BRYANT LR, SONG WS, BANKS KP, et al. Comparison of planar scintigraphy alone and with SPECT for the initial evaluation of femoral neck stress fracture . AJR Am J Roentgenol. 2008;191(4):1010-1015.
[21] SPIEGL UJ, BEISSE R, HAUCK S, et al. Value of MRI imaging prior to a kyphoplasty for osteoporotic insufficiency fractures. Eur Spine J. 2009;18(9):1287-1292.
[22] 高化,李锦军,王炳强,等.磁共振成像与核素骨显像对骨质疏松性椎体骨折诊断的比较[J]. 中国脊柱脊髓杂志,2011,21(8):675-679.
[23] NOMAYR A,ROMER W,STROBEL D,et al.Anatomical accuracy of hybrid SPECT/spiral CT in the lower spine. Nuclear Medicine Communications. 2006;27(6):521-528.
[24] 江晓兵,莫凌,姚珍松,等.SPECT、SPECT-CT与MRI对新鲜骨质疏松性椎体压缩骨折的诊断价值[J].中国脊柱脊髓杂志,2013,23(10):891-897.
[25] 包洁,邹达,李危石.椎体CT值评估腰椎退变患者骨密度的研究进展[J].中国脊柱脊髓杂志,2020,30(8):745-750.
[26] KIM KJ, KIM DH, LEE JI, et al. Hounsfield units on lumbar computed tomography for predicting regional bone mineral density. Open Med. 2019;14(1):545-551.
[27] CHEN HJ, XIAO ZG, YU RH, et al. CT measurement and analysis of the target vertebral body in elderly patients with uncompressed osteoporotic thoracolumbar fractures. Eur Rev Med Pharmacol Sci. 2018;22(1 Suppl):36-44.
[28] 王冬梅,朱秀芬,牡丹,等.腰椎体松质骨CT值在老年女性骨质疏松性骨折诊断中的价值[J].实用老年医学,2020,34(4):331-334+338.
[29] GARNER HW, PATURZO MM, GAUDIER G, et al. Variation in attenuation in L1 trabecular bone at different tube voltages: caution is warranted when screening for osteoporosis with the use of opportunistic CT. AJR Am J Roentgenol. 2017;208 (1):165-170.
[30] LEE SJ, BINKLEY N, LUBNER MG, et al. Opportunistic screening for osteoporosis using the sagittal reconstruction from routine abdominal CT for combined assessment of vertebral fractures and density. Osteoporos Int. 2016;27(3):1131-1136.
